Fabrication of Nanorod Array Structure by Using Aluminizing and Internal Oxidation of Ni with Micro-Channels

Abstract:

A metallurgical method for preparing oxide nano-rod array structure was developed with internal oxidation of Ni(Al) solid solution obtained by aluminizing Ni with a pack cementation technique. The present method was applied in order to fabricate nano-rod array on the micro-channel surface of microreactor. A micro-channel with 1 mm in depth, 1mm in width and 10 mm in length was fabricated on the Ni disk by an electric discharge machining and electropolishing. The Ni disk with a micro-channel was annealed at 1300°C for 12 h in vacuum. The sample was aluminized by a pack cementation using pack powder mixture consisting of 10 mass% of Ni3Al, 88 mass% of Al2O3 and 2 mass% of NaCl at 1100°C for 12 h in a flow of argon gas. The sample was oxidized from 1000 to 1200°C for 6 h with the Co/CoO buffer. Ni matrix in internally oxidized zone was removed by electropolishing to expose nano-rods. Al2O3 nano-rod array located on the micro-channel surface was successfully fabricated with the proposed technique. Diameter and height of nano-rods were ranged from 100 to 300 nm and from 1.5 to 3 µm, respectively.

• Periodical: Materials Science Forum (Volume 761)
• Pages: 131-134
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.761.131
• Online since: July 2013
• Authors: Takeshi Ishizaki, Dung Thi Mai Do, Makoto Nanko
• Keywords: Aluminizing, Internal Oxidation, Microreactor, Nanorod Array, Nickel

References

[1] S. Vaccaro, L. Malangone and P. Ciambelli: "Micro-Scale Catalytic Reactor for Syngas Production", Ind. End. Chem. Res. Vol. 49 (2010) pp.10924-10933.

DOI: 10.1021/ie100464b

[2] P. Watts, and S. J. Haswell: "The Application of Microreactors for Small Scale Organic Synthesis", Chem. Eng. Technol. Vol. 28 (2005) pp.290-301.

DOI: 10.1002/ceat.200407124

[3] D. G. Shchunkin and D. V. Sviridov: "Photocatalytic Processes in Spatially Confined Micro- and Nanoreactors", J. Photochem. Photobiol., C. Vol. 7 (2006) pp.23-39.

[4] A. Pohar, M. Lakner, and I. Plazl: "Parallel Flow of Immiscible Liquids in a Microreactor: Modeling and Experimental Study", Microfluid Nanofluid, Vol. 12 (2012) pp.307-316.

DOI: 10.1007/s10404-011-0873-7

[5] Y. Sekine, Y. Sato, Y. Matsushita, T. Suzuki and T. Ichimura: "Selective Oxidation of Organic Compounds in Microreactors with Immobilized Photocatalyst", Annu. Meeting. Jps. Soc. Mol. Sci.Vol. 4 (2009) 4P041.

[6] M. Nanko and D. T. M. Do: "Oxide Nano-rod Array Structure via a Simple Metallurgical Process: IOP Conf. Series", Mater. Sci. Eng. , Vol. 29 (2011) 012012.

DOI: 10.1088/1757-899x/20/1/012012

[7] M. Nanko, D. T. M. Do, and T. Ishizaki: "A Fabrication Method for Vertical Oxide Nano-rod Array by Internal Oxidation of Alloys at High-temperatures", Curr. Appl. Phys., Vol. 12 (2012) p. S184-S187.

DOI: 10.1016/j.cap.2012.03.002

[8] M. Nanko, K. Uemura and K. Takeda: "Nano Al2O3 Rod Array Structure Produced by Using Internal Oxidation of Dilute Ni(Al) Alloys", ECS Trans., 3 (14) pp.3-12 (2007).

DOI: 10.1149/1.2721454
