Modeling and Measurement of Residual Stresses along the Process Chain of Autofrettaged Components by Using FEA and Hole-Drilling Method with ESPI

Abstract:

The incremental hole-drilling method is a well-known mechanical measurement procedure for the analysis of residual stresses. The newly developed PRISM® technology by Stresstech Group measures stress relaxation optically using electronic speckle pattern interferometry (ESPI). In case of autofrettaged components, the large amount of compressive residual stresses and the radius of the pressurized bores can be challenging for the measurement system. This research discusses the applicability of the measurement principle for autofrettaged cylinders made of steel AISI 4140. The residual stresses are measured after AF and after subsequent boring and reaming. The experimental residual stress depth profiles are compared to numerically acquired results from a finite element analysis (FEA) with the software code ABAQUS. Sample preparation will be considered as the parts have to be sectioned in half in order to access the measurement position. Following this, the influence of the boring and reaming operation on the final residual stress distribution as well as the accuracy of the presented measurement setup will be discussed. Finally, the usability of the FEA method in early design stages is discussed in order to predict the final residual stress distribution after AF and a following post-machining operation.

• Periodical: Materials Science Forum (Volumes 768-769)
• Pages: 79-86
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.768-769.79
• Online since: September 2013
• Authors: Horst Brünnet, Dirk Bähre, Theo J. Rickert, Dominik Dapprich
• Keywords: Autofrettage, Electronic Speckle Pattern Interferometry (ESPI), Finite Element Analysis (FEA), Hole-Drilling Method, Residual Stress

References

[1] T. Seeger, M. Schön, J.W. Bergmann, M. Vormwald, Autofrettage I – Dauerfestigkeits-steigerung durch Autofrettage, Forschungsvereinigung Verbrennungskraftmaschinen e.V. (1993).

[2] E. Brinksmeier, J.T. Cammet, W. König, P. Leskovar, J. Peters, H.K. Tönshoff, Residual stresses: measurement and causes in machining processes, Annals of the CIRP 31/2 (1982) 491-509.

DOI: 10.1016/s0007-8506(07)60172-3

[3] E. Macherauch, V. Hauk, Eigenspannungen – Entstehung, Messung, Bewertung, DGM Oberursel, (1983).

[4] B. Scholtes, Eigenspannungen in mechanisch randschicht-verformten Werkstoffzuständen – Ursachen, Ermittlung und Bewertung, Habilitation, DGM, (1991).

DOI: 10.1002/mawe.19910221203

[5] D. Bähre, H. Brünnet, Simulation of removing Autofrettage-induced residual stress loaded layers by finite element analysis, Procedia Engineering 19 (2011) 9-15.

DOI: 10.1016/j.proeng.2011.11.072

[6] H. Brünnet, I. Yi, D. Bähre, Modeling of residual stresses and shape deviations along the process chain of Autofrettaged components, Journal of Materials Science and Engineering A 1/7A (2011) 915-936.

DOI: 10.4028/www.scientific.net/msf.768-769.79

[7] P.V. Grant, J.D. Lord, P.S. Whitehead, Measurement good practice guide No. 53 – The measurement of residual stresses by the incremental hole-drilling technique, National Physics Laboratory, UK, (2002).

[8] T. Rickert, R. Fix and L. Suominen, Comparison of Residual Stress Measurements Using X-Ray Diffraction and PRISM - Electronic Speckle Pattern Interferometry and Hole-Drilling, SAE Technical Paper (2007) 2007-01-0804.

DOI: 10.4271/2007-01-0804

[9] D.P. Kendall, A short history of high pressure technology from Bridgman to Division 3, J. Pressure Vessel Techn. 122 (2000) 229-233.

DOI: 10.1115/1.556178

[10] M. Lechmann, Entwicklung eines schwingbruchmechanischen Auslegungskonzepts für innendruckbeanspruchte Bauteile mit ausgeprägten Druckeigenspannungsfeldern, PhD Thesis, Stuttgart University, (2007).

[11] V. Läpple, Behälter unter Innen- und Außendruck, in: V. Läpple, Einführung in die Festigkeitslehre, 2nd edn, Vieweg + Teubner Verlag, Wiesbaden, 2008, pp.207-244.

DOI: 10.1007/978-3-8348-8281-3_12

[12] U. Fischer, Tabellenbuch Metall, Verlag Europa Lehrmittel, Haan-Gruiten, (2005).

[13] American Society of Mechanical Engineers, Boiler and Pressure Vessel Code - Section VIII, Division 3: Alternative Rules for construction of high pressure vessels, Article KD-5, (2010).

DOI: 10.1115/1.859872.ch23

[14] X.P. Huang, A general autofrettage model of a thick-walled cylinder based on tensile-compressive stress-strain curve of a material, J. Strain Analysis 40/6 (2005) 599-607.

DOI: 10.1243/030932405x16070
