Study on the Milling Technologies of Super-Slender Rod

Abstract:

t is well known that slender rod machining operation is a very difficult problem due to its low stiffness. During slender rod machining process, the deflection, vibration, cutting heat and cutting force of the machined part are the main reasons affecting the product quality. Based on the analysis of current research status of slender rod milling technology, process scheme, milling strategy, clamping fixture and tool designing is carried out in this work. In a roughing milling stage, we create a new strategy of square rod milling, called equilateral milling strategy to eliminating deflection. In finish-milling top waveform stage, a way using semicircle profile cutter to finish was applied. Complex interpolated movement is transform into simple two-dimension curved movement to shorten machine time and increase of efficiency in the way. In addition, machined surface with burnishing effect, high precision and high surface quality is obtained.

• Periodical: Materials Science Forum (Volume 770)
• Pages: 69-73
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.770.69
• Online since: October 2013
• Authors: Wei Ren, Wei Yu, Mao Su Zhou
• Keywords: Machining Deform, Precision Milling, Residual Stress, Super-Slender Rod

References

[1] Cui Bodi. Investigations on Cutting Parameter Optimization and Dimensional Error Monitoring System for Slender Bar. Harbin Institute of Technology Engineering PhD thesis(2008).

[2] Fan Xiong: Equipment Manufacturing Technology Vol. 1 (2011), p.115.

[3] Chen Hongxia: Machinery Manufacturing Technology. Peking University Press(2010).

[4] Wang Litao, Xu Lingping, Zhang Haitao, Wang Zhongjue: Journal of Anhui University of Technology and Science Vol. 2 (2004), p.36.
