High Temperature Tensile Behavior of Directionally Solidified MAR-M247 Superalloy

Abstract:

In this study, two heat treatment schemes were proposed to study the high temperature mechanical behavior of directionally solidified MAR-M247 superalloy. Two withdraw rates, namely, 60 and 180 mm/h were used to produce directionally solidified MAR-M247 specimens by the Bridgeman type furnace. Standard heat treatment (HT1) procedures are solution treatment at 1230°C for 2 h/ArC, then first aging at 980°C for 5 h/AC and followed by second aging at 870°C for 20 h/AC. Modified heat treatment (HT2) is solution treatment at 1260°C for 3 h/ArC and first aging at 980°C for 6 h/AC, then the same second aging procedure. Uneven size, shape and fusion-alike of gamma prime precipitates are observed after full HT1 scheme, whereas even size but fine gamma prime precipitates are observed in HT2 specimen. All three tensile properties (elongation to failure, ultimate tensile strength and yield strength) of HT2 specimens are higher than these of HT1 specimens either at room temperature 25°C or at high temperature 982°C for both withdraw rates. Uneven distribution of the γ′ precipitates attributes to the initial fracture of HT1 specimens.

• Periodical: Materials Science Forum (Volumes 783-786)
• Pages: 1153-1158
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.783-786.1153
• Online since: May 2014
• Authors: Hui Yun Bor*, Chao Nan Wei, An Chou Yeh, Wei Bin He, Huei Sen Wang, Chen Ming Kuo
• Keywords: Directional Solidification, Heat Treatment, MAR-M247 Superalloy, Tensile Behavior

References

[1] P.A.S. Reed, I. Sinclair, X.D. Wu, Fatigue crack path prediction in UDIMET 720 nickel-based alloy single crystals, Metall. Mater. Trans. A 31 (2000) 109–123.

DOI: 10.1007/s11661-000-0058-6

[2] M. Koble, K. Neuking, G. Eggeler, Dislocation reactions and microstructural instability during 1025°C shear creep testing of superalloy single crystals, Mater. Sci. Eng. A 234–236 (1997) 877–879.

DOI: 10.1016/s0921-5093(97)00366-3

[3] F. Sczerzene, G.E. Maurer, Developments in disc materials, Mater. Sci. Technol. 3 (1987) 733–742.

[4] J. Zheng, B.E. Powell, Effect of stress ratio and test methods on fatigue crack growth rate for nickel based superalloy Udimet720 , Int. J. Fatigue 21 (1999) 507–513.

DOI: 10.1016/s0142-1123(99)00009-2

[5] C.T. Sims, N.S. Stoloff, W.C. Hagel, Superalloy II, John Wiley and Sons, New York, (1987).

[6] M.T. Kim, S.Y. Chang, J.B. Won, Effect of HIP process on the micro-structural evolution of a nickel-based superalloy, Mater. Sci. Eng. A 441 (2006) 126–134.

DOI: 10.1016/j.msea.2006.09.060

[7] R.C. Kramb, M.M. Antony, S.L. Semiatin, Homogenization of a nickel-base superalloy ingot material, Scr. Mater. 54 (2006) 1645–1649.

DOI: 10.1016/j.scriptamat.2006.01.008

[8] K.L. Zeisler-Mashl, B.J. Pletka, Segregation During Solidification in the MAR-M247, in: S. D Antolovich, R.W. Stusrud, R.A. Mackay, D.L. Anton, T. Khan, R.D. Kissinger, D.L. Klarstrom (Eds. ), Superalloys 1992, TMS, Warrendale, PA, 1992, p.175.

DOI: 10.7449/1992/superalloys_1992_175_184

[9] S.R. Hegde, R.M. Kearsey, J.C. Beddoes, Designing homogenization-solution heat treatment for single crystal superalloys, Mater. Sci. Eng. A 527 (2010) 5528–5538.

DOI: 10.1016/j.msea.2010.05.019

[10] G.E. Fuchs, Solution heat treatment response of a third generation single crystal Ni-base superalloy, Mater. Sci. Eng. A 300 (2001) 52–60.

DOI: 10.1016/s0921-5093(00)01776-7

[11] H.Y. Bor, C.N. Wei, R.R. Jeng, P.Y. Ko, Elucidating the effects of solution and double ageing treatment on the mechanical properties and toughness of MAR-M247 superalloy at high temperature, Mate. Chem. Phy. 109 (2008), 334–341.

DOI: 10.1016/j.matchemphys.2007.11.041

[12] J.E. Doherty, B.H. Kear, A.F. Giamiei, Origin of ductility enhancement in Hf-doped Mar-M200, J. Metals 23 (1971) 59–62.

DOI: 10.1007/bf03355744

[13] H.E. Huang, C.H. Koo, Effect of solution-treatment on microstructure and mechanical properties of cast fine-grain CM247LC superalloy, Mater. Trans. 45 (2004) 1360–1366.

DOI: 10.2320/matertrans.45.1360

[14] M.V. Nathal, R.D. Maier, L.J. Ebert, The Influence of Cobalt on the Tensile and Stress-Rupture Properties of the Nickel-Base Superalloy MAR-M247, Metall. Mater. Trans. A 13 (1982) 1767–1774.

DOI: 10.1007/bf02647832

[15] M.V. Nathal, R.D. Maier, L.J. Ebert, The Influence of Cobalt on the Microstructure of the Nickel-Base Superalloy MAR-M247, Metall. Mater. Trans. A 13 (1982) 1775–1783.

DOI: 10.1007/bf02647833

[16] K. Harris, G.L. Erickson, R.E. Schwer, Mar M247 Derivations CM 247 LC DS Alloy CMSX Single Crystal Alloy Properties & Performance, in: M. Gell, C.S. Kortovich, R.H. Bricknell, W.B. Kent, J.F. Radavich (Eds. ), Superalloy 1984, TMS, Warrendale, PA, 1984, p.221.

DOI: 10.7449/1984/superalloys_1984_221_230

[17] H.Y. Bor, C.G. Chao, C.Y. Ma, The influence of magnesium on carbide characteristics and creep behavior of the MAR-M247 superalloy, Scr. Mater. 38 (1997) 329–335.

DOI: 10.1016/s1359-6462(97)00444-2

[18] S.M. Copley, B.H. Kear, G.M. Rowe, The temperature and orientation dependence of yielding in Mar-M200 single crystals, Mater. Sci. Eng. 10 (1972) 87–92.

DOI: 10.1016/0025-5416(72)90072-9

[19] R.R. Jensen, J.K. Tien, Temperature and strain rate dependence of stress-strain behavior in a nickel-base superalloy, Metall. Trans. A 16 (1985) 1049–1068.

DOI: 10.1007/bf02811675

[20] L.Z. He, Q. Zheng, X.F. Sun, G.C. Hou, H.R. Guan, Z.Q. Hu, Low ductility at intermediate temperature of Ni-base superalloy M963, Mater. Sci. Eng. A 380 (2004) 340–348.

DOI: 10.1016/j.msea.2004.03.057

[21] M.A. Meyers, K.K. Chawla, Mechianical Metallurgy, Prentice-Hall, (1984).

[22] G.E. Dieter, Mechianical Metallurgy, third edition, McGraw-Hill, New York, (1986).
