Complex Microstructural Banding of Continuously Cooled Carbide-Free Bainitic Steels

Abstract:

Chemical segregation of alloying elements during solidification of steel grades leads to development of a banded microstructure, causing a degree of anisotropy that can be detrimental to the mechanical behavior under service conditions. It is well-known that the presence of strongly orientated martensite bands in carbide-free bainitic microstructures, associated to inhomogeneous Mn redistribution during solidification, leads to a remarkable deterioration in toughness in advanced high strength bainitic steels. In this study, while bands were clearly visible on light optical micrographs of continuously cooled carbide-free bainitic steels, scanning electron microscopy examination revealed only a gradual transition between matrix and bands, both with a granular bainitic structure. Electron backscatter diffraction was used to quantify the bainitic packet size and volume fraction of martensite/austenite constituent between and within the bands, after a process of optimization of the analysis settings in order to minimize the inherent difficulties linked to sub-micrometric and minority phase indexation. The quantitative microstructural results showed negligible morphological differences between bainitic structure bands and matrix, only solute segregation of Cr and Mo was detected by energy-dispersive X-ray spectroscopy within bands, which must be responsible for a stronger resistance against metallographic etching in those regions.

• Periodical: Materials Science Forum (Volumes 783-786)
• Pages: 980-985
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.783-786.980
• Online since: May 2014
• Authors: Lucia Morales-Rivas*, Hans Roelofs, Stephan Hasler, Carlos Garcia-Mateo, Francisca G. Caballero
• Keywords: Bainite, EBSD, EDS, Microstructural Banding

References

[1] H.K.D.H. Bhadeshia, Phase Transformations contributing to the properties of modern steels, Bulletin of the Polish Academy of Sciences, Technical Sciences. 58 No 2 (2010).

DOI: 10.2478/v10175-010-0024-4

[2] P.G. Bastien, The mechanism of formation of banded structures, J. Iron and Steel Institute. 187 (1957) 281-291.

[3] J.S. Kirkaldy, J. von Destinon-Forstmann, R.J. Brigham, Simulation of banding in steels, Can. Metall. Q. 59 (1962) 59-81.

DOI: 10.1179/cmq.1962.1.1.59

[4] R.A. Jaramillo, M.T. Lusk, M.C. Mataya, Dimensional anisotropy during phase transformation in a chemically banded 5140 steel. Part I: experimental investigation, Acta Mater. 52 (2004) 851-858.

DOI: 10.1016/j.actamat.2003.11.017

[5] C.R. Brooks, Principles of the Austenitization of Steels, Chapter 6, Elsevier-Science (1992).

[6] F.G. Caballero, J. Chao, J. Cornide, C. García-Mateo, M.J. Santofimia, C. Capdevila, Toughness deterioration in advanced high strength bainitic steels, Mater. Sci. Eng., A. 525 (2009) 87–95.

DOI: 10.1016/j.msea.2009.06.034

[7] H. Roelofs, U. Urlau, M. Lembke, G. Olschewski, New bright bar multiphase steels with excellent machinability, 2nd Int Conf. On Steels in Cars and Trucks, Wiesbaden. (2008), 1-5.

[8] K.A. Ridal, J. McCann, Physical Properties of Martensite and Bainite, Special Report 93, Iron and Steel Institute (London) (1965) 147-148.

[9] Standard Test Method for Determining Volume Fraction by Systematic Manual Point Count, E 562 – 11 (2011).

[10] M.J. Dickson, Significance of Texture Parameters in Phase Analysis by X-Ray Diffraction, J. Appl. Crystallogr. 2 (1969) 176-180.

DOI: 10.1107/s0021889869006881

[11] A.F. Gourgues, H.M. Flower, T.C. Lindley, Electron backscattering diffraction study of acicular ferrite, bainite, and martensite steel microstructures, Mater. Sci. Technol. 16 (2000) 26–40.

DOI: 10.1179/026708300773002636

[12] J.M. Rodriguez-Ibabe, The Role of Microstructure in Toughness Behaviour of Microalloyed Steels, Mater. Sci. Forum. 284–286 (1998) 51–62.

DOI: 10.4028/www.scientific.net/msf.284-286.51
