Topology Option of Bias Magnetic Field for Magnetostrictive Actuator

Abstract:

In the design of giant magnetostrictive material (GMM) actuator, the bias magnetic field is a vital part. For the use of GMM rod in the magnetostrictive actuator, there are two typical topology structures, in-line structure and coaxial structure. Although these structures have been used in the design of magnetostrictive actuator, little work has been done to compare the general features for concrete application conditions. In this paper, we use finite element analysis (FEA) as the main tool to analyze and compare these structures and come to a conclusion that, as to a diameter-limited actuator, when the length to diameter ratio of the rod is less than 5, coaxial actuator can provide more uniform magnetic field and less moving parts; when the length to diameter ratio of rod is 5, the field inhomogeneity is nearly equal, and coaxial actuator uses less moving parts and in-line actuator cost less permanent magnet (PM); when the length to diameter ratio of rod is more than 5, in-line actuator can provide more uniform magnetic field and use less PM.

• Periodical: Materials Science Forum (Volume 787)
• Pages: 295-299
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.787.295
• Online since: April 2014
• Authors: Qing Xia, Tian Li Zhang*, Jin An Yu, Cheng Bao Jiang
• Keywords: Bias Magnetic Field, Length to Diameter Ratio, Magnetostrictive Actuator

References

[1] Wan Defu，Ma Xinglong .Physics of Magnetism Magnetic Materials.University of Electronic Science and Technology Press.November,1994.

[2] Savge H T,Clark A E,Pickart S J,etal. Effects of Annealing on The Coercivity of Amorphous TbFe2 [J].IEEE Transactions on Magnetic,1974,10(3):807~809.

[3] Clark A E, Lindgren E A. Development of Terfenol-D Transducer Material[J].Journal of Applied Physics,1998,83(11):7282~7284.

[4] HOU Shuping, YANG Qingxin. Characteristic and Application of Giant Magnetostrictive Material. Ordnance Material Science and Engineering. 2008, Vol.31 No.5.

[5] Meng Aihua Xiang Zhanqin. Effects of Bias Optimization on the Performances of a Terfenol-D Actuator. China Mechanical Engineering, 2004, Vol.16No.18.

[6] GUAN Xinchun, GUO Pengfei, OU Jin ping. Uniformity Design of Magnetic Field of Magnetostrictive Actuators Generated By Permanent Magnet Bias. Proc. of SPIE Vol. 6423, 64234A, (2007).

DOI: 10.1117/12.780121

[7] Myounggyu D. Noh and Young-Woo Park. Topology Selection and Design Optimization for Magnetostrictive Inertial Actuators. Journal of Applied Physics 111, 07E715 (2012).

DOI: 10.1063/1.3673431
