Analysis of Energy Consumption in the Dry Drilling of PEEK GF30

Abstract:

In this work, the energy required during the dry drilling of PEEK GF30, a thermoplastic material, polyether-ether-ketone, reinforced with glass fiber, is analyzed. Three different types of drills are used, respect to material and geometry, under nine cutting conditions based on cutting speed of 6000, 7000 and 8000 rpm, and feed rate of 300, 400 and 500 mm/min. The results show that similar outcomes are obtained with two drills, one of them, wolfram carbide with coating of TiAlN and another of wolfram carbide with point of diamond. This aspect is important due to the economic advantages of the first drill respect to the second one. An analysis of variance, ANOVA, shows that the drill type is the more influent factor, and that the optimal situation can be given with drill of WC and point of diamond with the higher cutting conditions. The energy required, assigned to the torques, is superior to 98%, in each case, question that could be taken in account in the tools design.

• Periodical: Materials Science Forum (Volume 797)
• Pages: 29-34
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.797.29
• Online since: June 2014
• Authors: Rosario Domingo*, Manuel García-García, Maria Rosa Gomez
• Keywords: Composite Material, Dry Drilling, Energy, PEEK GF30

References

[1] J.P. Davim, F. Mata, V. N Gaitonde, S.R. Karnik, Machinability Evaluation in Unreinforced and Reinforced PEEK Composites using Response Surface Models. Journal of Thermoplastic Composite Materials 23 (2010) 5-18.

DOI: 10.1177/0892705709093503

[2] J.P. Davim, P. Reis, Machinability study on composite (polyetheretherketone reinforced with 30% glass fibre–PEEK GF 30) using polycrystalline diamond (PCD) and cemented carbide (K20) tools. International Journal of Advanced Manufacturing Technology 23 (2004).

DOI: 10.1007/s00170-003-1779-7

[3] A.M. Abrao, P.E. Faria, J.C. Campos Rubio, P. Reis, J.P. Davim, Drilling of fiber reinforced plastics: A review. Journal of Materials Processing Technology 186 (2007) 1-7.

DOI: 10.1016/j.jmatprotec.2006.11.146

[4] R.V.S. Singh, B. Latha, V.S. Senthilkumar, Modeling and Analysis of Thrust Force and Torque in Drilling GFRP Composites by Multi-Facet Drill Using Fuzzy Logic. International Journal of Recent Trends in Engineering 1 (2009) 66-70.

[5] J. Campos Rubio, A.M. Abrao, P.E. Faria, A. Esteves Correia, J.P. Davim, Effects of high speed in the drilling of glass fibre reinforced plastic: Evaluation of the delamination factor. International Journal of Machine Tools and Manufacture 48 (2008).

DOI: 10.1016/j.ijmachtools.2007.10.015

[6] A.P. Singh, M. Sharma, I. Singh, A review of modeling and control during drilling of fiber reinforced plastic composites. Composites: Part B 47 (2013) 118–125.

DOI: 10.1016/j.compositesb.2012.10.038

[7] M.R. Spiegel, J. Schiller, R.A. Srinivasan, M. Stephens, Probability and Statistics (4th edition). McGraw-Hill, New York, USA, (2012).

[8] R. Domingo, M. García, M.A. Sebastián, Relationship Between Torques and Power Consumption in Dry Machining of UNS A92024-T3 Alloy. Annals of DAAAM 2011, 371-372.

DOI: 10.2507/22nd.daaam.proceedings.186

[9] R. Li, P. Hegde, A.J. Shih, High-throughput drilling of titanium alloys. International Journal of Machine Tools & Manufacture 47 (2007) 63–74.

DOI: 10.1016/j.ijmachtools.2006.02.012
