Residual Stresses Measurement Base on Three Reference Points Theory Using Contour Method

Abstract:

The objective of this work is to measure the residual stress normal to the cut plane which has a large size using contour method. Translations and rotations are applied to the second point cloud to assure the continuity of the contour. There is still the same work on the opposing cut plane, align and combine the two contour datasets, perform the interpolation and then integrate with a finite element modelling package to apply many thousands of different boundary conditions. The finite element result shows a good continuity indicating the success of transformation means applied on the point cloud. The result gets the stress distribution normal to the cut plane. Beam forming is simulated to study the residual stress distribution of the stretch-wrap bend forming, the residual stress from contour method and forming simulation present the same trend.

• Periodical: Materials Science Forum (Volumes 800-801)
• Pages: 726-730
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.800-801.726
• Online since: July 2014
• Authors: Kai Qin Yu*, Yin Fei Yang, Liang Li, Ning He, Bo Chen, Xue Feng Zhang
• Keywords: Contour Method, Finite Element, Point Cloud, Residual Stress, Transformation

References

[1] Michael B. Prime, Alan L. Kastengren. The Contour Method Cutting Assumption: Error Minimization and Correction, Experimental and Applied Mechanics. (2011) 6: 233-250.

DOI: 10.1007/978-1-4419-9792-0_40

[2] P. Pagliaro, M.B. Prime, J.S. Robinson , B. Clausen, H. Swenson, M. Steinzig, B. Zuccarello: Measuring Inaccessible Residual Stresses Using Multiple Methods and Superposition, Experimental Mechanics(2011)51: 1123-1134.

DOI: 10.1007/s11340-010-9424-5

[3] Feng Jingwu: Research on 3D surface splicing method based on three control points(Master thesis of Zhe Jiang Sci-Tec University, Hangzhou, China. 2011).

[4] Information on: http: /en. wikipedia. org/wiki/Rotation_matrix.

[5] Prime MB. Cross-sectional mapping of residual stresses by measuring the surface contour after a cut. J Eng Mater technol. (2001) 123(2): 162-8.

DOI: 10.1115/1.1345526

[6] Information on: http: /en. wikipedia. org/wiki/Bicubic_interpolation.

[7] Li Dafeng: Study on Stretching Technique of 7075 Aluminium Alloy Plate (Master thesis of Chongqing University, Chongqing, China 2012).

[8] Jin Chaohai, Zhou Xianbing, Diao Keshan, Li Xiaoxing: Finite element simulation of aluminum profile stretch-wrap bending and springback. Material Science &Technology. (2004) 12(4).

[9] Chuan Liu, Xiang Yi: Residual stress measurement on AA6061-T6 aluminum alloy friction stir butt welds using contour method. Materials and Design(2013) 46: 366-371.

DOI: 10.1016/j.matdes.2012.10.030
