Large Motor Rotor Machining with Static Pressure Center Frame Design

Abstract:

With the recent development of domestic hydropower industry, length, weight, size, material and structure of the rotor machining of large motors and generators manufactured workpiece special processing equipment and process methods have become increasingly demanding, aiming at market high precision, good quality, technical indicators have a good guarantee of the large rotor machining center with plenty of needs static frame, developed a long piece, big weight, material and structural special processing equipment. This equipment has proven high accuracy, good quality, technical indicators have a good guarantee to solve practical problems that exist in the above production. The large hydrostatic rotor machining center frame, not only to solve the large generators, turbine rotor shaft heavy machining of technical problems, but also to ensure the accuracy and stability of the product processing.

• Periodical: Materials Science Forum (Volumes 800-801)
• Pages: 864-868
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.800-801.864
• Online since: July 2014
• Authors: Yu Qing Wang*, Shi Gang Wang
• Keywords: Accuracy, Hydrostatic Center Rack, Weight, Workpiece
