Characterization of Nitrogen Doped Diamond Electrodes Produced by Hot Filament Chemical Vapor Deposition

Abstract:

The purpose of this work is to study the structural and morphological modification of the surface of the n-type diamond electrodes as a function of nitrogen doping. The characterizations of these electrodes were made using Raman Spectroscopy, Contact Angle, X-ray diffraction and Scanning Electron Microscopy (SEM). The nitrogen-doped diamond (NDD) electrodes were produced using Hot Filament-assisted Chemical Vapor Deposition method (HFCVD) from methane, hydrogen and nitrogen in the gas mixture. The results from Raman spectroscopy show that the diamond films obtained with nitrogen addition presented one large band at 1100-1700 cm^-1. The SEM images showed that the variation in the nitrogen doping influenced the growth rate of films by promoting changes in the sizes of grains from microcrystalline to nanocrystalline texture. This behavior supported the results obtained from X-ray diffraction analyses. It was possible to verify a decrease in the crystallite size as a function of the nitrogen increase.

• Periodical: Materials Science Forum (Volume 802)
• Pages: 180-185
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.802.180
• Online since: December 2014
• Authors: Nazir M. Santos*, Tatiane M. Arantes, Neidênei G. Ferreira, Mauricio R. Baldan
• Keywords: Diamond Electrodes, HFCVD, Nitrogen-Doped Diamond Film
