Effect of Nb₂O₅ Addition to the Electrical Properties of Fe₂TiO₅Ceramics-Based NTC Thermistor

Abstract:

The aims of this research is to identify the effect of Nb₂O₅ addition on the electrical properties of Fe₂TiO₅ ceramics-based NTC thermistor.The concentration of Fe₂O₃ and TiO₂ was proportional to Fe₂TiO₅, whereas the concentration value of Nb₂O₅were 0, 0.5 and 1.0 mole %, respectively. Within two hours, the mixed powder was pressed at 4 ton/cm² to form pellets and sintered at 1300 °C in air. It can perceived from the XRD data that the sintered ceramics had single phase of Fe₂TiO₅, pseudobrookite. From SEM data, it is found that addition of Nb₂O₅decreases the grain size. The addition of Nb₂O₅ increases thermistor constant, activation energy and electrical resistance of Fe₂TiO₅ ceramics. The values of thermistor constant of Nb₂O₅ added-Fe₂TiO₅ceramics were relatively large, indicated that the ceramics were aplicable as the NTC thermistor.

You might also be interested in these eBooks

Functional Properties of Modern Materials

View Preview

Info:

Periodical:

Materials Science Forum (Volume 827)

Pages:

262-265

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.827.262

Citation:

Cite this paper

Online since:

August 2015

Authors:

Wiendartun Wiendartun*, Risdiana Risdiana, Fitrilawati Fitrilawati, Rustam E. Siregar

Keywords:

Ceramic, Fe₂TiO₅, Nb₂O₅, NTC, Thermistor

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Eun Sang Na, Un Gyu paik, Sung Churl Choi, The effect of a sintered microstructure on the electrical properties of a Mn-Co-Ni-O thermistor, Journal of Ceramic Processing Research, 1 (2001) 31-34.

Google Scholar

[2] R. Metz, Electrical properties of NTC thermistors made of manganite ceramics of general spinel structure; Mn3-x-x'MxNx'O4(0≤x+x'≤1; M and N being Ni, Co or Cu). Aging phenomena study, Journal of Materials Science, 35 (2000) 4705-4711.

Google Scholar

[3] M. Vakiv, O. Shpotyuk, O. Mrooz, I. Hadzaman, Controlled thermistor effect in the system CuxNi1-x-y Co2y Mn2-y O4, Journal of the European Ceramic Society, 21 (2001) 1783-1785.

DOI: 10.1016/s0955-2219(01)00115-7

Google Scholar

[4] Wiendartun, D.G. Syarif, Electrical Characteristics of CuFe2O4 thick film ceramics with different glass concentrations fired at 1000oC for negative thermal coefficient (NTC) thermistor, Journal of Materials Science Research, 1 (2012) 70-75.

DOI: 10.5539/jmsr.v1n3p70

Google Scholar

[5] A. Feltz, W. Polzl, Spinel forming ceramics of the system Fex Niy Mn3-y-x O4 for high temperature NTC thermistor applications, Journal of the European Ceramics Society, 20 (2000) 2352-2366.

DOI: 10.1016/s0955-2219(00)00140-0

Google Scholar

[6] G. D. C. Csete de Gyorgyfalva, I. M. Reaney, Decomposition of NiMn2O4 spinel: an NTCthermistor material, Journal of the European Ceramics Society, 21 (2001) 2145-2148.

DOI: 10.1016/s0955-2219(01)00190-x

Google Scholar

[7] K. Park, I.H. Han, Effect of Al2O3 addition on the microstructure and electrical properties of (Mn0, 37Ni0, 3Co0, 33-xAlx)O4 (0 £ x £ 0. 03) NTC thermistors, Materials Science and Engineering B, 119 (2005) 55-60.

DOI: 10.1016/j.mseb.2005.01.018

Google Scholar

[8] A.J. Moulson., J.M. Herbert, Electroceramics, third ed., Chapman & Hall, New York, (2003).

Google Scholar

[9] Wiendartun, Waslaludin, Dani Gustaman Syarif, Effect of MnO2 addition on Characteristics of Fe2TiO5 Ceramics for NTC Thermistor utilizing Commercial and Local Iron Oxide, Journal of The Australian Ceramic Society, 49 (2013) 141-147.

Google Scholar
