Comparison of Three Different In-Wheel SMPM Motor Configurations Based on the Urban NEDC

Abstract:

Design optimization of traction motors for light electric vehicles over an operating point is an adequate way of achieving higher overall efficiency under a standard driving scheme of the vehicle. However, this work proves that a direct comparison of similar candidates regarding efficiency values under a predetermined operating point does not yield sufficient information on the economy achieved on a specific driving pattern per candidate. This paper presents a comparative study on three similar surface mounted permanent magnet in-wheel motor configurations. On a first step, these configurations are compared in terms of efficiency and performance over one operating point. On a second step, efficiency maps of the designs under study are utilized to provide a wider picture of their efficiency attributes. On the final step, the three configurations are simulated driving a prototype light electric vehicle in the Urban part of the New European Driving Cycle and the results are discussed.

• Periodical: Materials Science Forum (Volume 856)
• Pages: 233-238
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.856.233
• Online since: May 2016
• Authors: Christos Krasopoulos*, Minos Beniakar, Antonios G. Kladas
• Keywords: Driving Cycle, Efficiency Map, Electric Motor Design, Finite Element Simulation, In-Wheel Motor, Light Electric Vehicle, Unequal Stator Teeth

References

[1] C. Krasopoulos, M. Beniakar, P. Kakosimos, C. Patsios and A. Kladas, Design Considerations for an In-wheel PM Motor with Fractional Slot Concentrated Windings for Light Electric Vehicle Applications, Materials Science Forum, 792, pp.343-348, (2014).

DOI: 10.4028/www.scientific.net/msf.792.343

[2] Peter Sergeant and Alex P.M. Van den Bossche, Influence of the Amount of Permanent-Magnet Material in Fractional-Slot Permanent-Magnet Synchronous Machines, IEEE Trans. on Industrial Electronics, vol. 61, no. 9, pp.4979-4989, September, (2014).

DOI: 10.1109/tie.2013.2258310

[3] K. Laskaris, E. Theodorou, V. Papanikolaou and A. Kladas, High Efficiency Permanent Magnet Wheel Motor Design for Light Electric Vehicle Applications, Materials Science Forum, 721, 313, pp.313-318, June, (2012).

DOI: 10.4028/www.scientific.net/msf.721.313

[4] Jorge O. Estima and Antonio J. Marques Cardoso, Efficiency Analysis of Drive Train Topologies Applied to Electric/Hybrid Vehicles, IEEE Trams. on Vehicular Technology, vol. 61, No. 3, pp.1021-1031, March, (2012).

DOI: 10.1109/tvt.2012.2186993

[5] K. Kiyota, H. Sugimoto and A. Chiba, Comparing Electric Motors: An Analysis Using Four Standard Driving Schedules, IEEE Trans. on Industry Applications, vol. 20, no. 4, pp.12-20, July, (2014).

DOI: 10.1109/mias.2013.2288380

[6] M. Beniakar, P. Kakosimos, C. Krasopoulos, A. Sarigiannidis and A. Kladas, Comparison of In-wheel Permanent Magnet Motors for Electric Traction, XXIth International Conference on Electrical Machines, ICEM 2014, 2-5 Sep. 2014, Berlin, Germany, pp.2472-2478.

DOI: 10.1109/icelmach.2014.6960534

[7] A. Sarigiannidis, M. Beniakar, P. Kakosimos and A. Kladas, Multi-operating points PM motor design methodology for electric actuation systems, XXIth International Conference on Electrical Machines, ICEM 2014, 2-5 Sep. 2014, Berlin, Germany, pp.2472-2478.

DOI: 10.1109/icelmach.2014.6960539

[8] Guang Jin Li; Zi Qiang Zhu; Foster, M.; Stone, D., Comparative Studies of Modular and Unequal Tooth PM Machines Either With or Without Tooth Tips, in Magnetics, IEEE Transactions on , vol. 50, no. 7, pp.1-10, July (2014).

DOI: 10.1109/tmag.2014.2310179

[9] Lazari, P.; Jiabin Wang; Liang Chen, A Computationally Efficient Design Technique for Electric-Vehicle Traction Machines, in Industry Applications, IEEE Transactions on , vol. 50, no. 5, pp.3203-3213, Sept. -Oct. (2014).

DOI: 10.1109/tia.2014.2304619
