Cutting Temperature Experiment and Simulation Analysis of the Complex Groove Turning Insert

Abstract:

In order to study the complex groove inserts in the cutting process caused by temperature variation of cutting,Using multi factor cutting method and combined with finite element simulation technology, from cutting parameters and chip-breaking groove two aspects influence on cutting temperature and cutting force cutting tests were carried out and experimental study on the complex groove turning insert edge chamfering, rounded cutting edge radius on cutting temperature effects. Also tested the effects of temperature on the chip shape cutting and breaking, and analyzed the temperature on the Influence law of cutting tool wear, thus providing a theoretical basis for tool wear.

• Periodical: Materials Science Forum (Volume 861)
• Pages: 44-49
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.861.44
• Online since: July 2016
• Authors: Li Min Shi*, Cheng Yang
• Keywords: Cutting Parameters, Cutting Temperature, Friction Angle, Groove Type

References

[1] E.L. Liu, Research on Chip-breaking Capability and Maching Chip-breaking Predictive System with 3-D Complicated Grooved Inserts in Turning，Harbin Gongye Daxue Xuebao. (2007) 1-42.

[2] R. Komandui, Z.B. Hou. Analysis of heat partition and temperrature distribution in sliding systems, Wear. 250 (2001) 925-938.

DOI: 10.1016/s0043-1648(01)00707-4

[3] Y. Huang. Predictive modeling of tool wear rate with application to CBN hard turning, Atlanta Georgia Institute of Technology. (2002) 125-189.

[4] C.C. Song, S. Liu. Measurement of cutting temperature for multiple layercomposite cutting tips, Journal of Jiangsu University Science & Technology. (2001) 54-58.

[5] X.X. Wang, H.X. Wang. The development of finite element analysis for metal cutting process, Journal of Jiamusi University. (2006) 1-4.

[6] N.A. Abukhshim, P.T. Mativenga, M.A. Sheikh, Heat generation and temperature prediction in metal cutting: a review and implications for high speed machining, Int. J. Mach. Tools Manuf . 46 (2006) 782-800.

DOI: 10.1016/j.ijmachtools.2005.07.024

[7] Z.G. Huang, K.E. Ying-lin, L.T. Wang. Coupled thermo-mechanical model for metal orthogonal cutting process and finite element simulation, Hangkong Xuebao. 25 (2004) 317-320.

[8] Z. T Tang, Z.Q. Liu, X. Ai, X.L. Fu, A study of thermo-elastic-plastic large-deformation finite element theory and key techniques of metal cutting simulation, Zhongguo Jixie Gongcheng. 18 (2007) 746-751.

[9] X.M. Gao, B. Jiang, Thermal-coupling field analysis and high-speed cutting quality evaluation for the curve-edge turing insert, Modern Manufacturing Engineering. 29 (2009) 54-58.
