Structural Damage Assessment of FRP Strengthened Reinforced Concrete Beams under Cyclic Loads

Abstract:

Worldwide, the need for structural retrofit is on the rise and the use of Fibre Reinforced Polymer (FRP) composite material systems is becoming an accepted method for repairs, rehabilitations, and strengthening of deficient structures. The great qualities of the FRP materials, certified in the laboratories and confirmed in the fields have all contributed to propel the material as a very promising one, though more works need to be done to certify the fatigue resistance and durability criteria. This research looked at the experimental investigations of Reinforced Concrete (RC) beams strengthened flexurally with externally-epoxy bonded FRP laminates under four point cyclic loads. Dynamic tests are used to assess damages in the FRP-strengthened RC beams under cyclic loads. 6 RC beams of 150 x 200 mm cross-section and length of 2.20m and were reinforced with four 12mm ribbed longitudinal steel bars. Three types of FRP laminates made of high modulus carbon fibre, high strength carbon fibre and glass fibre were adopted. The results confirm that dynamic-based method is an efficient way of assessing damage evolution in RC beams strengthened with FRP laminates under cyclic loads. The results offered a criterion that can be adopted for quick assessment of the efficiency of FRP composite systems before applying them to civil applications.

• Periodical: Materials Science Forum (Volume 866)
• Pages: 139-142
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.866.139
• Online since: August 2016
• Authors: Anthony N. Ede*, Giovanni Pascale
• Keywords: Cyclic Loading, Damage Detection, Dynamic Test, FRP Laminates, RC Beam

References

[1] D. Schnerch and S. Rizkalla, Behaviour of Scaled Steel-Concrete Composite Girders and Steel Monopoles Towers Strengthened with CFRP, Proc. International Conference on Innovative Materials and Technologies for Construction and Restoration, June 6 – 9, 2004 ; Lecce – Italy.

DOI: 10.1201/9780203970850.ch4

[2] F. Goodman F, Cementitious Repair Materials for Concrete, An ACI 546R-04 Concrete Repair Guide presented at the ACI Spring 2005 Convention New York City.

DOI: 10.14359/51687319

[3] C.E. Bakis, L.C. Bank, V.L. Brown, E. Cosenza, J.F. Davalos, J.J. Lesko, A. Machida, S.H. Rizkalla, T.C. Triantafillou. Fiber Reinforced Polymer Composites for Construction-State of the Art Review. Journal of composites for Construction Vol. 6 No. 2, (2002).

DOI: 10.1061/(asce)1090-0268(2002)6:2(73)

[4] J.G. Teng, J.F. Chen, S.T. Smith and L. Lam. FRP-strengthened RC Structures. John Wiley & Sons Ltd, West Sussex, (2002), p.245.

DOI: 10.1002/pi.1312

[5] J.B. Quattlebaum and K.A. Harries. Comparison of three CFRP flexural retrofit systems under monotonic and fatigue loads. An internal report, Department of Civil Engineering, University of South Carolina, Colombia, SC 29208 (2003).

DOI: 10.1061/(asce)1084-0702(2005)10:6(731)

[6] H. Sohn C.R. Farrar, F.M. Hermez, J.J. Czarnecki, D.D. Shunk, D.W. Stinermates, B. Nadler, A Review of Structural Health Monitoring Literature, 1996-2001, Los Alamos National Laboratory Report, (2002).

[7] G. Pascaleand, B. Bonfiglioli. Reinforced Concrete Beams Damaged and repaired withGFRP: Dynamic Testing and Modelling. Proc. International conference on FRP Composites in Civil Engineering, J. -G Teng editor, Elsevier, Hong Kong, China, (2001).

[8] A.N. Ede, B. Bonfiglioli, G. Pascale, E. Viola, Dynamic assessment of damage evolution in FRP strengthened RC beams, Proceedings of the International Conference on Restoration, Recycling and Rejuvenation Technology for Engineering and Architecture Application, RRRTEA04, June 7-11, 2004, Cesena, Italy, pp.155-163.

[9] A.N. Ede, Structural Damage Assessment of FRP-Strengthened Reinforced Concrete Beams under Static and Fatigue Loads. (Unpublished PhD Thesis). Department of Innovative Engineering, Lecce, Italy: University of Salento. 2008, 189 pages.

DOI: 10.4028/www.scientific.net/msf.866.139

[10] K.L. Reifsneider, Fatigue in composite materials. Elsevier, New York. (1991).

[11] R. Talreya. Fatigue of composite materials. Technomic Publishing Company, Lancaster, Pa. (1987).
