Electrodeposition of Cu-Sn-Graphite-Al₂O₃ Composite Coatings and their Tribological Properties

Abstract:

In order to improve the wear resistance, ensure the self-lubricating property, Cu-Sn coatings were prepared on the basis of non-cyanide pyrophosphate-stannate and strengthened by combining sol-gel method and composite electroplating technology. In the paper, graphite Sol and Al₂O₃ Sol were added to the Cu-Sn electroplating solution to obtain nanoparticles enhanced Cu-Sn-graphite and Cu-Sn-graphite-Al₂O₃. The effect of graphite Sol and Al₂O₃ Sol addition on composite coatings was investigated, such as surface morphology, micro-hardness and tribological properties. The result shows that the incorporation of the graphite Sol and the Al₂O₃ Sol lead to change the structure of the composite coatings. When the additions of graphite Sol and Al₂O₃ Sol were 110mL/L and 40mL/L respectively, the graphite and Al₂O₃ particles are uniformly distributed in the Cu-Sn matrix and contribute greatly to improve the hardness and tribological properties of Cu-Sn alloy coating.

• Periodical: Materials Science Forum (Volume 893)
• Pages: 335-339
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.893.335
• Online since: March 2017
• Authors: Xiao Hui Wang, Li Xia Ying*, Chun Jie Zhang, Xiu Peng Lv
• Keywords: Cu-Sn-Graphite-Al₂O₃, Pulse Electrodeposition, Sol, Tribological Property

References

[1] Banerjee A, Kumar R, Dutta M, et al, Microstructural evolution in Cu–Sn coatings deposited on steel substrate and its effect on interfacial adhesion, Surface and Coatings Technology. 262 (2015) 200-209.

DOI: 10.1016/j.surfcoat.2014.12.049

[2] N. Pewnim, S. Roy, Electrodeposition of tin-rich Cu–Sn alloys from a methanesulfonic acid electrolyte, Electrochimica Acta, 90 (2013) 498-506.

DOI: 10.1016/j.electacta.2012.12.053

[3] Caterina Zanella, Sujie Xing, Flavio Deflorian, Effect of electrodeposition parameters on chemical and morphological characteristics of Cu–Sn coatings from a methanesulfonic acid electrolyte, Surface and Coatings Technology. 236 (2013) 394-399.

DOI: 10.1016/j.surfcoat.2013.10.020

[4] Gongjun Cui, Qinling Bi, Shengyu Zhu, et al, Tribological properties of bronze–graphite composites under sea water condition, Tribology International. 53 (2012) 76-86.

DOI: 10.1016/j.triboint.2012.04.023

[5] Majid Asnavandi, Mohammad Ghorbani, Mohaddeseh Kahram, Production of Cu–Sn–graphite–SiC composite coatings by electrodeposition, Surface and Coatings Technology. 216 (2013) 207-214.

DOI: 10.1016/j.surfcoat.2012.11.042

[6] WEI Wei，SUN Yuan，WEI Kun-xia，DU Qing-bo，HU Jing Preparation and Properties of Cu/Carbon Graphite Composites for Mechanical Seal, Journal of Materials Science and Engineering., 01 (2014) 15-19.

[7] R. K. GoyAl, M. Yadav. Study on wear and friction behavior of graphite flake-filled PTFE composites[J]. Journal Of Applied Polymer Science. 127 (2013) 3186-3191.

DOI: 10.1002/app.37707

[8] WANG Xuanlun，YANG Wenqing，LI Youbing，LIN Jingan，XIE Xingbo, Preparation and Properties of Polyethylene/Nano Graphite Platelet Conductive Composites, China Plastics., 01 (2012) 8-15.

[9] Yan J, Xu H, Xu Y, et al. Synthesis, Characterization and Photocatalytic Activity Of Ag/AgCl/Graphite-Like C3N4 Under Visible Light Irradiation[J]. Journal of Nanoscience & Nanotechnology. 14 (2014) 6809-6815P.

DOI: 10.1166/jnn.2014.8975

[10] WANG J, FENG Y, LI S, et al, Influence of graphite content on sliding wear characteristics of CNTs-Ag-G electrical contact materials, Transactions of Nonferrous Metals Society of China. 19 (2009) 113-118P.

DOI: 10.1016/s1003-6326(08)60237-x
