Filling of Microarray Fabricated by Micro Powder Injection Molding

Abstract:

Flow analysis during injection molding is crucial for dimensional control in micro powder injection molding. Numerical simulation of injection molding of ZrO₂ microarray based on in-house feedstock was conducted. A powder-binder two fluid model was developed to analyze temperature, viscosity and powder volume fraction of the feedstock for micro pillars of different dimensions with diameters of 0.2, 0.5 and 1 mm, respectively. In general the binder temperature decreased with size reduction of the micro cavity caved on the silicon wafer and increased with mold temperature. The micro pillars of φ0.2 mm exhibited the highest viscosity, which indicated difficulty for filling during injection molding. An increase in mold temperature facilitated the decrease of the feedstock viscosity, which improved the filling of the micro cavities. Powder-binder segregation became evident as the size of the micro cavities reduced to 0.2 mm.

• Periodical: Materials Science Forum (Volume 898)
• Pages: 1171-1176
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.898.1171
• Online since: June 2017
• Authors: Lin Liu*, M.X. Qi, Z.Q. Xie, Z.Y. He, F. Ming
• Keywords: Micro Powder Injection Molding, Microarray, Simulation, Submicron Zirconia Powder

References

[1] V. Piotter, T. Benzler, T. Gietzelt, R. Ruprecht, J . Hausselt, Micro powder injection moulding, Adv. Eng. Mater. 2 (2000) 639-642.

DOI: 10.1002/1527-2648(200010)2:10<639::aid-adem639>3.0.co;2-a

[2] T. Gietzelt, O. Jacobi, V. Piotter, R. Ruprecht, J. Hausselt, Development of a micro annular gear pump by micro powder injection moulding, J. Mater. Sci. 39 (2004)2113-2119.

DOI: 10.1023/b:jmsc.0000017774.64153.d9

[3] Liu L, Loh N H, Tay B Y, et al. Microstructure evolution of 316L stainless steel micro components prepared by micro powder injection molding[J]. Powder Technology, 2011, 206(3): 246-251.

DOI: 10.1016/j.powtec.2010.09.027

[4] Liu Z Y, Loh N H, Tor S B, et al. Characterization of powder injection molding feedstock[J]. Materials Characterization, 2002, 49(4): 313-320.

DOI: 10.1016/s1044-5803(02)00282-6

[5] Wang CM, Leonard RL, McCabe TJ. Prediction of defect formation in powder injection molding by computer simulation technique, P/M in aerospace, defense and demanding applications, San Diego, USA, 7-10 Feb, (1993).

[6] W. Cao, C. Shen, C. Zhang, L. Wang, Computing flow-induced stresses of injection molding based on the Phan–Thien–Tanner model, Archive of Applied Mechanics 78 (2008) 363-377.

DOI: 10.1007/s00419-007-0167-4

[7] M.K. Abdullah, M.Z. Abdullah, S. Kamarudin, Z.M. Ariff, Study of flow visualization in stacked-chip scale packages (S-CSP), International Communications in Heat and Mass Transfer 34 (2007) 820-828.

DOI: 10.1016/j.icheatmasstransfer.2007.04.003

[8] M. K. Abdullah, M. Z. Abdullah, M. A. Mujeebu, and S. Kamaruddin, A study of effect of epoxy molding compound (EMC) rheology during encapsulation on stacked-CHIP scale packages (S-CSP), Journal of Reinforced Plastics and Composites, September 4(2008).

DOI: 10.1177/0731684408092409

[9] L.V. Dihoru, L.N. Smith, R. Orban, R.M. German, Mater. Manuf. Process. 15 (3) (2000) 419-438.

[10] TIAN Z, CAO W, SHEN C. Numerical simulation of flow-induced stress in injection molding[J]. Chinese Journal of Computational Mechanics, 2008, 5: 017.

[11] XU H, XIONG W, YE D. Research Status and Prospect of Computer Simulation of Powder Injection Molding Filling Process [J]. Materials Review, 2006, 11: 024.

[12] Yimin L, Xuanhui Q, Boyun H, et al. The Flow Behavior and Viscosity Determination of the Feedstock of Metal Injection Molding [J]. Rare Metal Materials and Engineering, 1996, 26(1): 41-43.
