Multimicrophone Measurement of Semi-Active Samples in an Acoustic Tube

Abstract:

The sample of a piezoelectric semi-active shunt damping material is analyzed inside an acoustic tube. The measurement of reflected and transmitted acoustic wave through the sample is realized using 4-microphone measurement method. Acoustic properties of the sample with the emphasis on acoustic transmissibility are analyzed. The composite piezoelectric sample comprising of a piezoelectric material connected to a linear shunting circuit is described, also the multimicrophone measurement methods are described in detail and the results are discussed in context of semi-active sound damping.

• Periodical: Materials Science Forum (Volume 919)
• Pages: 386-395
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.919.386
• Online since: April 2018
• Authors: Michal Kašpárek*, Martin Černík, Jana Urbánková, Pavel Mokrý
• Keywords: Acoustic Impedance Tube, Acoustic Transmission, Four-Microphone Method, Negative Impedance Converter, Piezoelectric Shunt Damping, Semi-Active Shunt Damping

References

[1] J.S. Bolton, T. Yoo, O. Olivieri, Measurement of Normal Incidence Transmission Loss and Other Acoustical Properties of Materials Placed in a Standing Wave Tube, Brüel & Kjær Technical Review No. 1, ISSN: 0007–2621.

[2] M. Date, M. Kutani, S. Sakai, Electrically controlled elasticity utilizing piezoelectric coupling, Journal of Applied Physics 87 (2) (2000) 863–868.

DOI: 10.1063/1.371954

[3] S. Behrens, A. J. Fleming, S. O. R. Moheimani, Electromagnetic shunt damping, Proceedings of the 2003 IEEE/ASME AIM 2003, VOLS 1 AND 2, pages: 1145-1150, ISBN:0-7803-7759-1.

DOI: 10.1109/aim.2003.1225504

[4] M. Černík, P. Mokrý, Sound reflection in an acoustic impedance tube terminated with a loudspeaker shunted by a negative impedance converter, Smart Materials and Structures, Volume 21, Issue 11 (November 2012), ISSN: 0964-1726.

DOI: 10.1088/0964-1726/21/11/115016

[5] M. Kašpárek, M. Černík, Experimental verification of an Electromagnetic Shunt Damping circuit parameters producing an anechoic surface inside an acoustic tube, Proceedings of the 2016 17th ICCC 2016.

DOI: 10.1109/carpathiancc.2016.7501116

[6] Information on https://www.smart-material.com/MFC-product-main.html.

[7] T. Sluka, P. Mokry, Feedback control of piezoelectric actuator elastic properties in a vibration isolation system, Ferroelectrics vol. 351, June 2007, pp.51-61.

DOI: 10.1080/00150190701353051

[8] E. Fukada et al., Sound isolation by piezoelectric polymer films connected to negative capacitance circuits, IN: IEEE Transactions on Dielectrics and Electrical Insulation, vol. 11, no. 2, pp.328-333, Apr 2004.

DOI: 10.1109/tdei.2004.1285904

[9] Kolbrek, B., Horn Theory: An Introduction, Part 1, audioXpress, March 2008, [online], <http://www.audioxpress.com/assets/upload/files/kolbrek2884.pdf>.
