The Fabrication of Multicolor Electrochromic Device Based on RGO/BOPP Using Ag Nanoparticles

Abstract:

In this research, we focused on silver (Ag) nanoparticles that exhibit various colors on the basis of their localized surface plasmon resonance (LSPR). The effects of step-voltage parameters on the coloration of the Ag deposition-based electrochromic device were investigated. Further, we report the use of reduced graphene oxide (RGO)/biaxially oriented polypropylene (BOPP) as the transparent conductive electrode. RGO was synthesized directly from graphite under a microwave heating system. BOPP film was coated with RGO by drop-casting method. The samples were characterized by X-ray diffraction (XRD), scanning electron microscopy (SEM), transmission electron microscope (TEM), energy dispersive spectroscopy (EDS), electrical resistance measurements and cyclic voltammetry (CV). The SEM and TEM images exist as typical wrinkled structure, folded region, transparent, indicating these layers are exfoliated to a very large extent. Our results primarily indicate that the novel BOPP/RGO/Ag/RGO/BOPP configuration presents an easy and expeditious way of preparing the voltage-tunable multicolor electrochromic device. The electrochromic device can be switched from the transparent state to the black state and yellow state.

• Periodical: Materials Science Forum (Volume 926)
• Pages: 79-84
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.926.79
• Online since: July 2018
• Authors: Achanai Buasri*, Suparak Ojchariyakul, Patinya Kaewmanechai, Waratchaya Eakviriyapichat, Vorrada Loryuenyong
• Keywords: Ag Nanoparticles, Biaxially Oriented Polypropylene, Localized Surface Plasmon Resonance, Multicolor Electrochromic Device, Reduced Graphene Oxide

References

[1] U. Abaci, H. Y. Guney, U. Kadiroglu, Morphological and electrochemical properties of PPy, PAni bilayer films and enhanced stability of their electrochromic devices (PPy/PAni–PEDOT, PAni/PPy–PEDOT), Electrochim. Acta 96 (2013) 214-224.

DOI: 10.1016/j.electacta.2013.02.120

[2] D. Evecan, O. Gurcuoglu, E. O. Zayim, Electrochromic device application of tungsten oxide film with polymer electrolytes, Microelectron. Eng. 128 (2014) 42-47.

DOI: 10.1016/j.mee.2014.05.031

[3] A. Tsuboi, K. Nakamura, N. Kobayashi, Chromatic control of multicolor electrochromic device with localized surface plasmon resonance of silver nanoparticles by voltage-step method, Sol. Energy Mat. Sol. Cells 145 (2016) 16-25.

DOI: 10.1016/j.solmat.2015.07.034

[4] A. Tsuboi, K. Nakamura, N. Kobayashi, A localized surface plasmon resonance-based multicolor electrochromic device with electrochemically size-controlled silver nanoparticles, Adv. Mater. 25 (2013) 3197-3201.

DOI: 10.1002/adma.201205214

[5] A. Tsuboi, K. Nakamura, N. Kobayashi, Multicolor electrochromism showing three primary color states (cyan-magenta-yellow) based on size- and shape-controlled silver nanoparticles, Chem. Mater. 26 (2014) 6477-6485.

DOI: 10.1021/cm5039039

[6] G. Bhattacharya, S. Sas, S. Wadhwa, A. Mathur, J. McLaughlin, S. S. Roy, Aloe vera assisted facile green synthesis of reduced graphene oxide for electrochemical and dye removal applications, RSC Adv. 7 (2017) 26680-26688.

DOI: 10.1039/c7ra02828h

[7] B. Subramanya, D. K. Bhat, Novel eco-friendly synthesis of graphene directly from graphite using 2,2,6,6-tetramethylpiperidine 1-oxyl and study of its electrochemical properties, J. Power Sources 275 (2015) 90-98.

DOI: 10.1016/j.jpowsour.2014.11.014

[8] V. Loryuenyong, K. Totepvimarn, P. Eimburanapravat, W. Boonchompoo, A. Buasri, Preparation and characterization of reduced graphene oxide sheets via water-based exfoliation and reduction methods, Adv. Mater. Sci. Eng. 2013 (2013).

DOI: 10.1155/2013/923403

[9] A. Buasri, J. Patwiwattanasiri, N. Adisaisakunchai, A. Kemngen, V. Loryuenyong, The production and properties of polylactide (PLA) nanocomposites filled with graphene oxide (XGO), Optoelectron. Adv. Mater. - Rapid Comm. 9 (2015) 507-510.

[10] M. Qian, Y. S. Zhou, Y. Gao, T. Feng, Z. Sun, L. Jiang, Y. F. Lu, Production of few-layer graphene through liquid-phase pulsed laser exfoliation of highly ordered pyrolytic graphite, Appl. Surf. Sci. 258 (2012) 9092-9095.

DOI: 10.1016/j.apsusc.2012.06.006

[11] A. Buasri, T. Ananganjanakit, N. Peangkom, P. Khantasema, K. Pleeram, A. Lakaeo, J. Arthnukarn, V. Loryuenyong, A facile route for the synthesis of reduced graphene oxide (RGO) by DVD laser scribing and its applications in the environment-friendly electrochromic devices (ECD), J. Optoelectron. Adv. Mater. 19 (2017).

[12] A. Buasri, D. Ongmali, P. Sriboonpeng, S. Prompanut, V. Loryuenyong, Development of transparent electrodes using graphene nano-ink and post-consumer PET bottles for electrochromic application, Key Eng. Mater. 744 (2017) 463-467.

DOI: 10.4028/www.scientific.net/kem.744.463
