Middle Shelf During Ductile to Brittle Transition on Ferrite + Pearlite Structure Steel Sheet

Abstract:

The steels consisting of multi-phase structure show an advantage for their high strength and good formability. The ductile to brittle transition with decreasing temperature has been investigated by Charpy impact test with sub-size specimen for the ferrite + pearlite structure steel sheet. The transition curve of the absorbed energy showed a two-step transition behavior, and the “middle shelf” appeared clearly in the curve. The cleavage-like fracture with few dimples appeared on the fracture surface of the specimens at the middle shelf, and the plastic strain was detected just below the fracture surface. This result suggested that the fracture at the middle shelf propagates with the quasi-cleavage fracture accompanied with plastic deformation. Although the traces of fracture surface corresponded to (001), (011), and (112) bcc-iron planes, the (001) cleavage plane was not dominant for the fracture propagation path at the middle shelf.

• Periodical: Materials Science Forum (Volume 941)
• Pages: 453-457
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.941.453
• Online since: December 2018
• Authors: Hiroyuki Kawata*, Osamu Umezawa
• Keywords: Cleavage Fracture, Ductile to Brittle Transition, Quasi-Cleavage Fracture, Steel

References

[1] M. Calcagnotto, D. Ponge, D. Raabe, Effect of grain refinement to 1 µm strength and toughness of dual-phase steels, Mater. Sci. Eng. A 527 (2010) 7832–7840.

DOI: 10.1016/j.msea.2010.08.062

[2] S. S. M. Tavares, P. D. Pedroza, J. R. Teodósio, T. Gurova, Mechanical properties of a quenched and tempered dual phase steel, Scripta Mater. 40 (1999) 887–892.

DOI: 10.1016/s1359-6462(99)00042-1

[3] H. Kawata, O. Umezawa, Two step ductile to brittle transition behavior on ferrite + pearlite structure steel sheet, ISIJ Int. 57 (2017) 1282–1288.

DOI: 10.2355/isijinternational.isijint-2017-026

[4] H. Kawata, O. Umezawa, Crystallographic characterization of the middle shelf in a two-step ductile to brittle transition for a ferrite + pearlite structure steel sheet, Mater. Sci. Eng. A 716 (2018) 252–259.

DOI: 10.1016/j.msea.2018.01.030

[5] A. Uehira, S. Ukai, Empirical correlation of specimen size effects in Charpy impact properties of 11Cr–0.5Mo–2W, V, Nb ferritic-martensitic stainless steel, J. Nuc. Sci. Technol. 41 (2004) 973–980.

DOI: 10.1080/18811248.2004.9726320

[6] T. Sirithanakorn, M. Tanaka, K. Higashida, Brittle-to-ductile transitions and its relation to the deformability of cementite in fully pearlitic steels, Mater. Sci. Eng. A611 (2014) 383–387.

DOI: 10.1016/j.msea.2014.06.007

[7] G. R. Odette, On the ductile to brittle transition in martensitic stainless steels—Mechanisms, models and structural implications, J. Nuc. Mater. 212–215 (1994) 45–51.

DOI: 10.1016/0022-3115(94)90032-9

[8] J.P. Naylor, P.R. Krahe, Cleavage planes in lath type bainite and martensite, Metall. Trans. A 6A (1975) 594–598.

DOI: 10.1007/bf02658424

[9] P. Mohseni, J.K. Solberg, M. Karlsen, O.M. Akselsen, E. Østby, Application of combined EBSD and 3D-SEM technique on crystallographic facet analysis of steel at low temperature, J. Microsc. 251 (2013) 45–56.

DOI: 10.1111/jmi.12041

[10] Y. Tomota, Y. Xia, K. Inoue, Mechanism of low temperature brittle fracture in high nitrogen bearing austenitic steels, Acta Mater. 46 (1998) 1577–1587.

DOI: 10.1016/s1359-6454(97)00350-9
