Microscopic Failure Mechanism of Zinc Layer in Galvanized Sheet during Sheet Forming Process

Abstract:

Sheet forming of galvanized metals presents a great challenge for automobile industry. This is partially caused by a significant induced plastic deformation and high contact friction during forming, which results in pulverization, flaking and failure seen in the zinc layer. Cupping tests is used to study the formability of the galvanized sheets, for a better understanding of microscopic failure mechanisms of the zinc layer. The results show that during the cupping of the galvanized sheet, the zinc layers of each deformed zone encounter varying degrees of failure behaviors. The regions next to the fillets of the punch and the blank holder ring are more serious. In these severe failure areas, the residual stresses in the zinc layer are shown as tensile in nature; and increase with the degree of deformation increasing. The galvanized layers rupture prematurely prior to any damage seen in the steel substrate; thus leading to chalking, flaking and final failure. The results provide a theoretical guidance for improving formability of galvanized sheets.

• Periodical: Materials Science Forum (Volume 944)
• Pages: 254-258
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.944.254
• Online since: January 2019
• Authors: Yao Huang, Lei Gang Wang*, Xiang Ma, Lei Liu
• Keywords: Failure, Fracture, Galvanized Sheet, Sheet Forming, Zinc Layer

References

[1] S. Dong, N. Zhou, Effect of TiC coating on electrode tip surface on electrode degradation during resistance spot welding zinc coated steel, The Chinese Journal of Nonferrous Metals, 15(2) (2005) 184-191.

[2] Q. Zhang, B. Liu, Recent development in study of effect of coating phase structure of IF galvannealed steel sheet on its properties, Iron and Steel, 37(12) (2002) 65-68.

[3] J. Yu, J. Zhang, J. Wu, Overview of propeties of zind layer of galvanized steel for auto industry (in Chinese), Physical and Chemical Testing - Physical Part, 41(9) (2005) 325-328.

[4] Y. Zheng, Q. Fu, J. Xun, Factor analysis influencing cupping tests (in Chinese), Physical and Chemical Testing - Physical Part, 40(9) (2004) 446-447.

[5] A. Hu, D. Kong, W. Zhu, Influence of residual stress in TiN coating on interfacial bonding strength (in Chinese), Tooling technology, 42(11) (2008) 34-36.

[6] H.Y. Kim, B.C. Hwang, W.B. Bae, An experimental study on forming characteristics of pre-coated sheet metals, Journal of Materials Processing Technology, 120(1-3) (2002) 290-295.

DOI: 10.1016/s0924-0136(01)01088-3

[7] S. Chen, L. Wang, Y. Huang, Failure analysis of a galvanized steel during cupping test (in Chinese), High temperature processing technology, 40(21) (2011) 191-193.
