Position Control and Alignment of the CCM Equipment

Abstract:

The improved technology of position control and alignment of the continuous casting machine (CCM) equipment based on high-precision online geodetic measurements is considered. The mathematical model for the technological axis of the continuous casting machine, the technique of the rational alignment of the machine’s equipment and the software implementing this technique are proposed. The application experience of the developed technique for control and aligning the equipment of continuous casting machines of different types is shown. The data on the efficiency of the technique for continuous casting machine equipment and its impact on the quality of a continuously cast ingot are presented.

• Periodical: Materials Science Forum (Volume 946)
• Pages: 644-649
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.946.644
• Online since: February 2019
• Authors: Andrei Sholomitskii*, Aleksey Sotnikov
• Keywords: Casting, Continuous Casting Machine, Electronic Total Station, Geodetic Measurements, Model, Statistical Mechanics, Steel, Technological Axis

References

[1] K.N. Vdovin et al., Improvement of steel pouring in section CBCM, Metallurgist. 58(3/4) (2014) 306-309.

DOI: 10.1007/s11015-014-9906-2

[2] A.L. Sotnikov et al., Continuous casting of steel at bar-casting machines in Ukraine and Moldova, Steel in Translation. 43(12) (2013) 808-814.

DOI: 10.3103/s0967091213120152

[3] P.O. Maruschak et al., Scale levels of damage to the raceway of a spherical roller bearing, Engineering Failure Analysis. 59 (2016) 69-78.

DOI: 10.1016/j.engfailanal.2015.11.019

[4] A.K. Verma et al., Design of Tundish Nozzles Alignment System for Multistrand Billet Casters in Continuous Casting Shop, 14th National Conf. on Machines and Mechanisms (NaCoMM-09), December 17-18, 2009, Durgapur (India), 372-379.

[5] D. Spinelli, Laser Alignment for the Caster Machine Repair Aisle, AISE Steel Technology. 1 (2002) 46-47.

[6] E.N. Smirnov et al., Problems of improving the equipment of continuous casting machines, XIII Int. Scientific Conf. New technologies and achievements in metallurgy and materials engineering,: a collective monograph, Chap.1, Iss. 24, Wydawnictwo Wydziału Inżynierii Procesowej, Materiałowej i Fizyki Stosowanej Politechniki, Częstochowskiej, 2012, pp.69-76.

[7] Departmental construction norms BCH 396-85. Installation of technological equipment of steelworks, (1986).

[8] O.A. Timohin, Peculiarities of calculation of the technological axis of the continuous casting machine and its control, Steel. (Iss. 2) (2000) 16-21.

[9] Danieli Service customer technical support: Is your conticasteraligned properly? Danieli News. (170) (August 2014) 98-99.

[10] Industrial 3-D Surveying with Optical Instruments, GLM Lasermeßtechnik GmbH, Witten, Germany, (2007).

[11] Laser Tracker use in industrial maintenance: machine and plant engineering, Press Release from Automated Precision, Mannheim, Germany, (2007).

[12] Information on http://newdimensions.ru/kalibrovochnoye-oborudovaniye.

[13] A.A. Sholomitskij, Control of the geometric parameters of continuous casting machine, Metallurgical processes and equipment. 3 (2007) 27-30.

[14] A.L. Sotnikov, Alignment control of CCM equipment, Metallurgical processes and equipment. 1 (2006) 24-27.

[15] S.G. Mogilny et al. Development of control technologies of position and alignment of CCM equipment, Metallurgical processes and equipment. 3 (2012) 12-25.

[16] S.G. Mogilny et al. Measuring complex Vizir 3D, on enterprises in Ukraine: Geodetic control and process equipment alignment, Metallurgical processes and equipment. 3 (2009) 12-19.

[17] A.A. Sholomitskij, A.L. Sotnikov High-precision measuring complex Vizir 3D,, Prostoev.NET. 1 (2014) 52-58.

[18] A.L. Sotnikov, A.A. Sholomitskii, Monitoring alignment of mold oscillatory motion with CCM process stream axis, Metallurgist. 60(9-10) (2017) 1046-1053.

DOI: 10.1007/s11015-017-0406-z
