Threaded Failure Analysis for Three-Dimensional Horizontal Wells Casing

Abstract:

In view of the external thread fracture during casing running in a well in Xinjiang Oilfield, the failure reasons of thread fracture were analyzed by combining the theory with experiment, and the casing safe service window with harsh working conditions was given. The operation of the failed casing and determined the actual working conditions of the casing threaded joints during the running process were investigated in this paper. According to the theoretical method, the boundary conditions and load conditions of the fracture casing joint in service were determined. With the aid of full-scale physical simulation test device, as well as the above boundary conditions and load conditions, the same batch casing tensile bearing characteristics were determined. Through nondestructive testing, the metallographic observation, scanning electron microscopy, spectral analysis and up-and-down test, the main controlling factors of casing thread fracture were determined. By the finite element analysis, the casing threads service state under axial tension and bending loads was established, the safety performance of threads under ideal working conditions was studied, and the fatigue mechanism of threads was revealed. Combined with the analysis results, the corresponding relationship between the casing tensile bearing characteristics and safety factor was given, which provides technical support for the safe service selection of casing body and thread under harsh conditions, saving cost and shortening the well construction period.

• Periodical: Materials Science Forum (Volume 993)
• Pages: 1155-1159
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.993.1155
• Online since: May 2020
• Authors: Rong Li Nan, Xin Sun, Bo Zhao Shu, Hang Wang, Shang Yu Yang, Cai Hong Lu*, Li Hong Han
• Keywords: Casing, Horizontal Wells, Threaded Failure, Three Dimensional

References

[1] S. Talebi, T. J. Boone, S. Nechtschein. A Seismic Model of Casing Failure in Oil Fields[J]. Pure and Applied Geophysics, 1998, 153(1): 197-217.

DOI: 10.1007/s000240050192

[2] Peng Wang, Qingjie Zhu, Xiangying Bu. Finite element analysis on Casing Failure Based on ADINA[J]. Systems Engineering Procedia, 2011, 1(0): 42-47.

DOI: 10.1016/j.sepro.2011.08.008

[3] Niu Jingtai, Peng Youwen, Wu Congcong, et al. Cement Loop Damage-based Fracture Mechanism during Repair of Casing Failure Well[J]. Procedia Earth and Planetary Science,2012,5(1): 322-325.

DOI: 10.1016/j.proeps.2012.01.054

[4] Deng Kuanhai, Lin Yuanhua, Liu Wanying, et al. Experimental investigation of the failure mechanism of P110SS casing under opposed line load[J]. Engineering Failure Analysis,2016,65(2): 65-73.

DOI: 10.1016/j.engfailanal.2016.04.002

[5] Yonggui Guo, Mark Blanford, Joseph Candella. Evaluating The Risk Of Casing Failure Due To High-Density Perforation: A 3D FEM Case Study From A Deep Water Reservoir, GoM. SPE Annual Technical Conference and Exhibition,2014, 170618.

DOI: 10.2118/170618-ms

[6] C. I. Noshi, S. F. Noynaert, J. J. Schubert. Failure Predictive Analytics Using Data Mining: How to Predict Unforeseen Casing Failures? Abu Dhabi International Petroleum Exhibition & Conference, 2018, 193194.

DOI: 10.2118/193194-ms

[7] Kenta Yamada, Kenji Furui. Efficient Integration Method of Large-Scale Reservoir Compaction and Small-Scale Casing Stability Models for Oilfield Casing Failure Analysis. SPE Asia Pacific Oil and Gas Conference and Exhibition, 2018, 192004.

DOI: 10.2118/192004-ms
