Physico-Chemical Properties of Nano ZrO₂-Pillared Bentonite with Nickel as Supporting Metal

Abstract:

Bentonite was modified through intercalation and calcination using a ZrOCl₂ pillaring solution. To create nano Ni/ZrO₂-bentonite catalyst, ZrO₂ pillared bentonite was impregnated using Ni(NO₃)₂•6H₂O precursor first, then followed by calcination and reduction. The physical-chemical properties of the catalyst was characterized by XRD (X-ray Diffractometer), FT-IR (Fourier Transform Infrared), surface acidity with NH₃ vapor adsorption method, SAA (Surface Area Analyzer) and TEM (Transmission Electron Microscope). The results of characterization with XRD showed specific peaks for montmorillonite minerals with a monoclinic crystalline type and its chemical composition (Ca)(Al,Mg)₆(Si₄O₁₀)₃(OH)₆.nH₂O and after pillarization showed a shift in basal spacing d₀₀₁ to the left (angle 2θ <5°). The typical peak indicating basal spacing d₀₀₁ shift towards a smaller angle of 2θ was not very apparent after impregnation with nickel metal. Qualitative determination of acidity after adsorption of ammonia showed characteristics at 1404-1635 cm^-1 wavenumbers with increasingly sharp spectra indicating increased acidity of the catalyst (Brǿnsted and Lewis acids). Surface area showed a significant increase from 27.385 m²/g to 174.208 m²/g after pillarization and impregnation of nickel metal.

• Periodical: Nano Hybrids and Composites (Volume 30)
• Pages: 9-17
• DOI: https://doi.org/10.4028/www.scientific.net/NHC.30.9
• Online since: November 2020
• Authors: Mohamad Mirzan, Akhmad Syoufian, Karna Wijaya*
• Keywords: Bentonite, Intercalation, Nickel, Wet Impregnation, ZrO₂

References

[1] A.Vaccari, Preparation and Catalytic Properties of Cationic and Anionic Clays, Catal. Today, 41, (1998) 53-71.

DOI: 10.1016/s0920-5861(98)00038-8

[2] A. De-Stefanis, A. G. Tomlinson, Towards Designing Pillared Clays for Catalysis, Catal. Today, 114 : (2006) 126-141.

DOI: 10.1016/j.cattod.2006.01.019

[3] G. Nagendrappa, Organic Synthesis Using Clay Catalysts, Resonance, 7, (2002) 64-77.

[4] H. Faghihian, M. H. Mohammadi, Surface Properties of Pillared Acid-Activated bentonite as Catalyst for Selective Production of Linear Alkylbenzene, Appl. Surf. Sci., 264, (2013) 492-499.

DOI: 10.1016/j.apsusc.2012.10.050

[5] F. Bergaya, B. K. G. Theng, G. Lagaly, (Eds.), 2006, Handbook of Clay Science, 1st ed. Elsevier, Amsterdam.

[6] F. Bergaya, A. Aouad, T. Mandalia, Pillared clays and clay minerals, in: F. Bergaya, B.K.G. Theng, G. Lagaly (Eds.), Developments in Clay Science, Elsevier, Amster- dam, (2006), p.393–421.

DOI: 10.1016/s1572-4352(05)01012-3

[7] A. Gil, S. A. Korili, R. Trujillano, M. A. Vicente, A Review on Characterization of Pillared Clays by Specific Techniques, Appl. Clay Sci., 53, (2011) 97-105.

DOI: 10.1016/j.clay.2010.09.018

[8] A. G. Tomlinson, Characterization of Pillared Layered structures, J. Por. Mat., 5: (1998) 259-274.

[9] M. Mirzan, K. Wijaya, I. I. Falah, W. Trisunaryanti, Synthesis and Characterization of Ni/ZrO2-bentonite, Asian J. Chem., 31, 1, (2019) 229-234.

DOI: 10.14233/ajchem.2019.21665

[10] K. Wijaya, E. Sugiharto, Mudatsir, I. Tahir, I. Liawati, Synthesis of Iron Oxide-Montmorillonite Composite and Study of Its Structural Stability Againts Sulfuric Acid, Indonesian J. Chem., 4(1), (2004) 33-42.

DOI: 10.22146/ijc.21871

[11] N. Ahmad, S. T. Hussain, B. Muhammad, N. Ali, S. M. Abbas, and Z. Ali, Zr-Pillared Montmorillonite Supported Cobalt Nanoparticles for Fischer-Tropsch Synthesis, Prog. Nat. Sci.: Materials International, 23(4), (2013) 374-381.

DOI: 10.1016/j.pnsc.2013.06.010

[12] M. R. S. Kou, S. Mendioroz, V. Nunoz, Evaluation of The Acidity of Pillared Montmorillonites by Pyridine Adsorption, Clays Clay Miner., 48(5), (2000) 528-536.

DOI: 10.1346/ccmn.2000.0480505

[13] E. M. Torres-Farfan, E. Sham, P. Grange, Pillared Clays: Preparation and Characterization of Zirconium Pillared Montmorillonite, Catal. Today, 15, (1992) 515-526.

DOI: 10.1016/0920-5861(92)85016-f

[14] S. V. Awate, S. B. Waghmode, M. S. Agashe, Synthesis, Characterization and Catalytic Evaluation of Zirconia-pillared Montmorillonite for Linear Alkylation of Benzene, Catal. Commun. 5, (2004) 407-411.

DOI: 10.1016/j.catcom.2004.04.005

[15] F. Tomul, Effect of Ultrasound on The Structural and Textural Properties of Copper-Impregnated Cerium-Modified Zirconium-Pillared Bentonite, Appl. Surf. Sci., 258, (2011) 1836-1840.

DOI: 10.1016/j.apsusc.2011.10.056

[16] A. Grosman, C. Ortega, Capillary Condensation in Porous Material, Hysteresis and Interaction Mechanism without Pore Blocking/Percolation Process , American Chemical Society, Langmuir, 24, 8, (2008) 3977-3986.

DOI: 10.1021/la703978v

[17] A. Suseno, K. Wijaya, W. Trisunaryanti, M. Shidiq, Synthesis and Characterization of ZrO2-Pillared Bentonites, Asian J. Chem., 27(7), (2015) 2619-2623.

DOI: 10.14233/ajchem.2015.18599
