Phase Change of Zr-Al-N and Nb-Al-N Films Prepared by Magnetron Sputtering Method

Abstract:

In order to examine the critical content of AlN for phase change from B1 type to B4 type, Zr-Al-N and Nb-Al-N pseudobinary films were synthesized with an inductively combined rf-plasma assisted magnetron sputtering method. From phase identification of these films by XRD and Raman scattering methods, it is found that phase change from B1 structure to B4 one occurs in the range from 30mol%AlN to 35mol%AlN for Zr-Al-N pseudobinary films and from 62mol%AlN to 70mol%AlN for Nb-Al-N pseudobinary films. The critical AlN content for Zr-Al-N pseudobinary films shows excellent agreement with the value (33mol%AlN) predicted by band parameters. The critical content for Nb-Al-N pseudobinary films is larger than the predicted value (53mol%AlN). It is suggested that the disagreement is attributed to a highly defective structure in Nb-Al-N pseudobinary films.

• Periodical: Solid State Phenomena (Volume 127)
• Pages: 195-200
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.127.195
• Online since: September 2007
• Authors: Yukio Makino, Kesami Saito, Yoshihiro Murakami, Katsuhiko Asami
• Keywords: Nb-Al-N Film, Phase Change, Pseudobinary Nitride, Raman Spectra, Zr-Al-N Film

References

[1] L.Hultoman: Vacuum, Vol.57(2000),p.1.

[2] S.PalDey and S.C. Deevi: Mater. Sci. Eng. Vol.342(2003),p.58

[3] J.Musil: Surf. Coat. Technol. Vol125(2000), p.322.

[4] S.Zhang, D.Sun, Y.Fu and H.Du: Surf. Coat. Technol. 167(2003), p.113.

[5] M.Hirai, Y.Ueno, T.Suzuki, W.Jiamg, C.Grigoriu and K.Yatsui: Jpn. Appl. Phys. Vol40(2000), p.1056.

[6] R. Prange, R.Cremer and N.Neuchütz: Surf. Coat. Technol. Vol133-134(2000)208.

[7] H.Kawate, A.Kimura, T.Suzuki: Surf. Coat. Technol. Vol.165(2003), p.163.

[8] K.Yamamoto, T.Sato, K.Takahara and K.Hanaguri: Surf. Coat. Technol. Vol.174-175 (2003),p.620

[9] Y.Makino: Surf. Coat. Technol. Vol.193(2005),p.185

[10] Y.Makino: Mater. Sci. Forum Vol.502(2005), p.81

[11] A.Sugishima, H.Kajioka and Y.Makino: Surf. Coat. Technol. Vol.97(1997),p.590

[12] T.Suzuki, Y.Makino, M.Samandi and S.Miyake: J. Mater. Sci. Vol.35(2000),p.208

[13] H.Kawate, A.Kimura, T.Suzuki: J. Vac. Sci. Technol. Vol.A20(2)(2002), p.569.

[14] K.Kutschej, P.H. Mayrhofer, M.Kathrein, P.Polcik, T.Tessadri and C.Mitterer: Surf. Coat. Technol. Vol.200(2004),p.2358.

DOI: 10.1016/j.surfcoat.2004.12.008

[15] Y.Makino, M.Mori, S.Miyake, K.Saito and K.Asami: Surf. Coat. Techinol. Vol.193 (2005),p.219

[16] W.Spengler and R.Kaiser: Solid State Commun. Vol.18(1976),p.881

[17] W.Spengler, R.Kaiser and H.Bilz: Solid State Commun. Vol.17(1976),p.19

[18] M.-S.Wong, G.Y. Hsiao and S.Y. Yang: Surf. Coat. Technol. Vol.133-134(2000)160.
