Development of Mathematical Model of a Mechatronic System

Abstract:

This paper is a continuation of earlier publications of the authors related to the analysis of mechatronic systems including piezoelectric materials used as sensors or actuators for stabilization and damping of mechanical vibration. It was demonstrated that only very accurate mathematical model of the system with the piezoelectric transducers and external electric circuit attached to a mechanical system like a beam or a shaft by a glue layer allows the engineers to design the system with required dynamic parameters. Geometrical and material parameters of all the components have to be taken into account because neglecting the influence of one of them results in erroneous analysis results [1-4]. The paper presents the improved mathematical model of the considered mechatronic system. The assumption of pure shear of the connection layer is rejected during modeling and deformation of the layer is taken into consideration. The purpose of the reported enhancement of the mathematical model of the considered mechatronic system is to improve accuracy of computational results.

• Periodical: Solid State Phenomena (Volume 164)
• Pages: 319-322
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.164.319
• Online since: June 2010
• Authors: Andrzej Buchacz, Marek Płaczek
• Keywords: Actuator, Control, Damping, Deformation, Elasticity, Mechatronics, Sensor, Smart Materials, Vibration

References

[1] A. Buchacz, M. Płaczek: Damping of Mechanical Vibrations Using Piezoelements, Including Influence of Connection Layer's Properties on the Dynamic Characteristic, Solid State Phenomena Vols. 147-149 (2009).

DOI: 10.4028/www.scientific.net/ssp.147-149.869

[2] M. Pietrzakowski: Influence of glue layers on vibration damping of composite plates, Proceedings of XVIIIth Symposium Vibrations in Physical Systems, Poznań-Błażejewko, (1998), pp.225-226.

[3] S. O. Reza Moheimani, A. J. Fleming: Piezoelectric transducers for vibration control and damping. Springer (2006).

[4] A. Tylikowski: Stabilization of beam parametric vibrations, Jurnal of Theoretical and Applied Mechanics 3, 31, (1993), pp.657-670.

[5] W. Kurnik: Damping of mechanical vibrations utilising shunted piezoelements. Machine Dynamics Problems. Vol. 28, No 4 (2004), pp.15-26.

[6] R. Kurowski, M. E. Niezgodziński: Wytrzymałość Materiałów, PWN, Warszawa (1970).
