Sensitivity and Stability Analysis of Mu-Synthesis AMB Flexible Rotor

Abstract:

The paper presents the sensitivity and stability margin analyses of the flexible rotor supported by active magnetic bearings (AMBs) with the robust optimal vibrations control. The modal representation of the rotor finite element model (FEM) is investigated. Then, the open-loop system of the AMBs flexible rotor is established and critical speed analysis due to variation of bearing stiffness is performed. For the open-loop setup, the non-collocation effect of displacement sensors and magnetic actuators due to control stability problem is considered. The frequency mode analysis of the collocation and non-collocation system is presented. Next, the -synthesis control of 4-DOF AMBs rotor is investigated. The design process of -controllers, which cover uncertainty design and performance shape by chosen weighting function is shortly described. Then, the sensitivity function is calculated and used to evaluate the AMBs rotor stability margin for the -control and the PID control. The performance of the -controller are verified in experimental tests.

• Periodical: Solid State Phenomena (Volume 164)
• Pages: 313-318
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.164.313
• Online since: June 2010
• Authors: Arkadiusz Mystkowski
• Keywords: Active Magnetic Bearing System, Critical Speed Map, Flexible Mode Shapes, Non-Collocation, Rotor FEM, Sensitivity Analysis, Stability Margin, μ-Synthesis Control

References

[1] M. Ito, H. Fujiwara, N. Takahashi, and O. Matsushita: Evaluation of Stability Margin of Active Magnetic Bearing Control System, Trans. Of JSME, 71, 708 (2005).

[2] Z. Gosiewski, A. Mystkowski: Robust control of active magnetic suspension: analytical and experimental results, Mechanical Systems & Signal Processing, Vol. 22, No. 6 (2008), p.12971303.

DOI: 10.1016/j.ymssp.2007.08.005

[3] Z. Gosiewski, A. Mystkowski: Optimal control of active rotor suspension, Archives of Control Sciences, Vol. 17, No. 4 (2007), pp.357-366.

[4] J. E. Mottershead: On the Zeros of Structural Frequency Response Functions and theirs Sensitivities, Mechanical Systems and Signal Processing, 12 (1998), pp.591-597.

DOI: 10.1006/mssp.1998.0167

[5] A. Preumont: Vibration Control of Active Structures, Kluwer Academic Publishers (1997).

[6] G. Schweitzer, E. H. Maslen: Magnetic Bearings: Theory, Design and Application to Rotating Machinery, Springer (2009).

DOI: 10.1007/978-3-642-00497-1

[7] K. Zhou, J. C. Doyle: Essentials of Robust Control, Prentice Hall (1997).

[8] The MathWorks, Robust Control Toolbox User's Manual, 3rd ed. (2004).

[9] ISO 14839-2: Mechanical vibration, Vibration of rotating machinery equipped with active magnetic bearings, Part 2: Evaluation of vibration (2004).

DOI: 10.3403/03128633u

[10] ISO 14839-3: Mechanical vibration, Vibration of rotating machinery equipped with active magnetic bearings, Part 3: Evaluation of stability margin (2006).

DOI: 10.3403/30128400u
