Mechatronic Design of a Planar Parallel Robot Actuated by Pneumatic Artificial Muscles

Abstract:

The pneumatic actuation is widely used in robotics. The actuators based on pneumatic artificial muscles are unconventional actuation systems which use the shortening by increase of the volume property which generate an axial force. They have a very good force/volume ratio and some advantages compared with conventional pneumatic actuation. This paper presents the mechatronic design of a PRRRP Biglide planar parallel robot actuated by four artificial muscles in antagonist configuration. The control system is based on an 8-bit microcontroller based development board and the position and force control is made by means of pressure regulation using proportional pressure regulators. It was determined the workspace of PRRRP Biglide parallel robot for different strokes of actuators using discretisation method in Matlab environment.

• Periodical: Solid State Phenomena (Volumes 166-167)
• Pages: 57-62
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.166-167.57
• Online since: September 2010
• Authors: Sorin Besoiu, Vistrian Măties, Donca Radu
• Keywords: Biglide, Control, Mechatronics, Pneumatic Artificial Muscle (PAM), Workspace

References

[1] Mătieş V., Mândru D., Bălan R., Tătar O., Rusu C.: Tehnologie şi educaţie mecatronică, Editura. Todesco, Cluj-Napoca (2001).

[2] Hesse: The Fluidic Muscle in Application - 150 practical examples using the Pneumatic Muscle, Blue Digest in Automation, Festo, Germany (2003).

[3] Frank Daerden: Conception and Realization of Pleated Pneumatic Artificial Muscles and their Use as Compliant Actuation Elements, PhD Thesis, Vrije Universiteit Brussel, Belgium.

[4] Chou C.P., Hannaford B.: Measurement and modeling of artificial muscles. IEEE Transactions on Robotics and Automation, 12, 90-102 (1996).

DOI: 10.1109/70.481753

[5] Klute G.K., Czerniecki J., Hannaford B.: Muscle-like pneumatic actuators for below-knee prostheses. Actuator 2000: 7th International Conference on Neu, Actuators, Bremen, Germany, 289-292 (2000).

[6] Stan, S. -D. Maties, V. Balan, R., Workspace analysis of the Biglide mini parallel robot with 2 DOF, Advanced Robotics and Its Social Impacts, ARSO 2007. IEEE Workshop (2007).

DOI: 10.1109/arso.2007.4531419

[7] Festo Company - Fluidic muscle applications and datasheet, http: /www. festo. com/cms/enus_us/5030. htm.
