A Polishing Method of Single-Incentive Ultrasonic Elliptical Vibration for Tungsten Carbide Mould

Abstract:

The basic principles of ultrasonic transducer and ultrasonic elliptical vibration polishing are investigated. A new kind of single-incentive ultrasonic transducer is designed, and the finite element simulation is conducted, a polishing device is developed based on the ultrasonic elliptical vibration. The polishing experiment is adopted to polish a tungsten carbide mold with the diameter 5cm. The experimental result shows that the tungsten carbide mould surface roughness changes from the original 0.026μm to 0.017μm.

• Periodical: Solid State Phenomena (Volume 175)
• Pages: 140-144
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.175.140
• Online since: June 2011
• Authors: Shao Hui Yin, Zhi Qiang Xu, Jian Wu Yu, Ze Biao Wang
• Keywords: Elliptical Vibration, Polishing, Single-Incentive, Tungsten Carbide Mould

References

[1] F.J. Chen, S.H. Yin, H. Huang, et al: International Journal of Machine Tools and Manufacture Vol. 50 (2010), p.480.

[2] G.E. Miller: Journal of Applied Physics, Vol. 2 (1957), p.149. 3] H.T. Suzuki. Moriwaki: Manufacturing Technology, (2006), p.385.

[4] K. Burhanettin, C. Serra: IEEE Vol. 49 (2002), p.495.

[5] X. Li and et al: Acat Aeronautica et Astronautica Sinica, Vol. 31(2005), p.156.
