Simulation Studies of the Effect of Shaft's Nonlinear Flexural Stiffness Parameters for Critical States of Rotating Power Transmission Systems

Abstract:

The paper presents simulation studies, performed using Simulink, the impact of nonlinear flexural stiffness of shafts for critical speed range and amplitude of vibration. The tests were performed on the selected model of a rotating machine, consisting of a drive, two torsional vibration dampers, shaft with mounted on it two rigid rotors (discs), supported on a three self-aligning roller bearings and mechanical power receiver (brake). The machine startup and braking with crossing the critical states was simulated using specialized Simulink library, which was developed by authors for analysis of transient states in rotating machines and flexural-torsional couplings. In accordance with the concept of modeling adopted by the authors, rotating system is divided into inertial rigid elements (rotors, bearings, clutches, etc..) and compliance elements (parts of the shaft). The main component of the currently developed library is block modeling rigid rotor with 6 degrees of freedom and with the static and dynamic unbalance. By assumption the library is a modular, expandable and allows modeling the systems of any configuration. The goal of the simulation was to verify how nonlinear flexural stiffness of shaft influences the values of critical speeds and the level of flexural and torsional vibrations.

• Periodical: Solid State Phenomena (Volume 236)
• Pages: 62-69
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.236.62
• Online since: July 2015
• Authors: Tomasz Matyja*, Bogusław Łazarz
• Keywords: Nonlinearity, Rotor Dynamics, Simulink

References

[1] P. Deuszkiewicz: Research static and dynamic properties of machine shafts made of composite carbon-epoxy (in Polish). ZN Akademii Marynarki Wojennej, Gdynia 2011. No. 185A, pp.75-82.

[2] P. Deuszkiewicz, R. Pakowski: The dynamics of nonlinear power transfer systems (in Polish). XXVI Sympozjon Podstaw Konstrukcji Maszyn, Szczyrk 9-13. 09. (2013).

[3] P. Deuszkiewicz, Z. Dąbrowski: Nonlinear dynamic model of carbon-epoxy composite structure. 20th International Congress on Sound and Vibration., 7–11 July 2013 Bangkok Thailand, Book of Abstract & CD.

[4] J. Kiciński: Rotor dynamics. Wydawnictwo IMP PAN (Written in English). Instytut Technologii Eksploatacji in Gdańsk, Radom. 2006. 539 p.

[5] G. Genta: Dynamics of Rotating Systems. Springer. NY. 2005. 658 p.

[6] M. B. Wagner, A. Younan, P. Allaire, R. Cogill: Model Reduction Methods for Rotor Dynamic Analysis. International Journal of Rotating Machinery, Vol. 2010, Article ID 273716, 17 p.

DOI: 10.1155/2010/273716

[7] B. Łazarz, T. Matyja Simulation of the non-steady states in rotating power transmission systems with use of Simulink. 20th International Congress on Sound and Vibration, Bangkok. Thailand, 7–11 July 2013. Book of Abstract. CD.

[8] T. Matyja: Model of stiff rotor with six degrees of freedom. 20th International Congress on Sound and Vibration. Bangkok, Thailand, 7–11 July 2013. Book of Abstract. CD.
