Numerical Modelling of Layered Composite Materials with Embedded Optical Fiber Sensors

Abstract:

One of the crucial points in making materials with embedded optical fiber sensors is obtaining information about stress-strain state which helps to asses the influence of embedded optical fibers on integral mechanical properties of the structure and redistribution of stresses and strains in the area around optical fibers. In this paper models of woven composite material with embedded optical fibers are studied with numerical results achieved with the help of finite element method in case of GFRP VPS-33 material with fabric filler T-10-14 and epoxy resin ENFB-2M. Numerical results about the change of stiffness parameters of plate specimens in cases of tension and bending are obtained. Evaluation of stress state change near embedded optical fiber in different cases of optical fiber orientation with respect to loading and in the presence and absence of resin pocket defect with polyamide optical fiber coating taken into account is given in this study.

• Periodical: Solid State Phenomena (Volume 243)
• Pages: 83-88
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.243.83
• Online since: October 2015
• Authors: Valery V. Korepanov*, Grigory S. Serovaev, Nataliia A. Yurlova
• Keywords: Composite Materials, Numerical Modeling, Optical Fibers, Sensors

References

[1] Balac I., Milovancevic M., Uskokovic P., Aleksic R., Stress field analysis around optical fiber embedded in composite laminae under transverse loading, FME Transactions. 34 (2006) 53-56.

[2] Jensen D.W., Pascual J., August J.A., Performance of graphite/bismaleimide laminates with embedded optical fibers. Part I: uniaxial tension, Smart Mater. Struct. 1 (1992) 24-30.

DOI: 10.1088/0964-1726/1/1/004

[3] Roberts S.S.J., Davidson R., Mechanical Properties of Composite Materials Containing Embedded Fibre Optic Sensors, SPIE Fiber Optic Smart Structures and Skins. 4 (1991) 326-341.

DOI: 10.1117/12.50193

[4] Bhargava A., Shivakumar K., Emmanwori L., Stress concentration and failure in composite laminates embedded with fiber optic sensor, 44th AIAA/ASME/ASCE/AHS structures, structural dynamics, and material conference. (2003) 1-13.

DOI: 10.2514/6.2003-1848

[5] Shivakumar K., Bhargava A., Failure mechanics of composite laminate embedded with a fiber optic sensors, Journal of Comp. Mat. 9 (2005) 77-798.

DOI: 10.1177/0021998305048156

[6] Shivakumar K., Emmanwori L., Mechanics of Failure of Composite Laminates with an Embedded Fiber Optic Sensor, Journal of Comp. Mat. 8 (2005) 669-680.

DOI: 10.1177/0021998304042393

[7] Dasgupta A., Wan Y., Sirkis J.S., Prediction of resin pocket geometry for stress analysis of optical fibers embedded in laminated composites, Smart Mater. Struct. 1 (1992) 101-107.

DOI: 10.1088/0964-1726/1/2/001

[8] Zuev M.A., Mahsidov V.V., Fedotov M. Yu., Shienok A.M., K voprosu ob integratsii optovolokna v PKM i izmerenii deformatsii materiala s pomoschyu volokonnyih breggovskih reshetok, Russian journal Mekhanika Kompositsionnykh Materialov i Konstruktsii 4 (2014).
