Mechanical Behavior of 3D Printed Stochastic Lattice Structures

Abstract:

Stochastic lattice structures are modeled using a generative algorithm. In particular, the voronoi tessellation technique is applied for modeling cellular solids with irregular cell geometry and variable strut sections. The ligaments are formed considering the volume and shape characteristics of the voronoi cells. This way, the strut cross section variability is linked to the adjacent cell topology. The developed geometry is used for 3D printing the structures through a high accuracy SLA 3D printer. The mechanical properties of the photosensitive resin were determined by conducting tension experiments on appropriate 3D printed specimens. The printed stochastic structures were subjected to compressive loads in order to investigate their mechanical response. A finite element model of the compressive tests using the generated geometry, is also developed. The calculated results provide a good correlation with the experimental ones and also provide precious insight for the characterization of the mechanical behavior of the tested structures.

• Periodical: Solid State Phenomena (Volume 258)
• Pages: 225-228
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.258.225
• Online since: December 2016
• Authors: Georgios Maliaris*, Elias Sarafis
• Keywords: Finite Element Analysis (FEA), Lattice Structures, Mechanical Behavior, Regular, Stochastic, Voronoi

References

[1] L.J. Gibson and M.F. Ashby, Cellular Solids – Structure and Properties (Cambridge University Press, UK 1997).

[2] S. Amin Yavari, S. M. Ahmadi, R. Wauthle, B. Pouran, J. Schrooten, H. Weinans, and A. A. Zadpoor. J Mech Behav Biomed Mater, Vol. 43 (2015), p.91.

DOI: 10.1016/j.jmbbm.2014.12.015

[3] J. Kadkhodapour, H. Montazerian, A. C. Darabi, A. P. Anaraki, S. M. Ahmadi, A. A. Zadpoor and S. Schmauder. J Mech Behav Biomed Mater, Vol 50 (2015), p.180.

[4] G. Maliaris and N. Michailidis, Modeling of open cell structures geometry and mechanical response applying the Voronoi tessellation algorithm, 5th International Conference on Manufacturing Engineering, ICMEN 2014, 1-3 October, 2014, Thessaloniki, Greece, ISBN 978-960-98780-9-8, pp.393-402.

[5] G. Maliaris, Mechanical and Fracture Behaviour of Cellular Materials with Regular and Random Lattice Structures under Various Compressive Velocities, 4th International Conference of Engineering Against Failure (ICEAF IV), 24-26 June, 2015, Skiathos, Greece, ISSN: 2241-5890, pp.555-562.
