On the Influence of Internal Void Size on the Fracture Stress of Constrained Solder Joints

Abstract:

The fracture strengths of thin solder joints were investigated experimentally and with Finite Element Analysis. Due to a constraining effect, thin solder joints can carry loads which are much higher than the ultimate tensile strength of bulk solder material. On the other hand, thin solder joints show a tendency of being brittle. In fact, the tensile properties show a dependence on the quality of the intermetallic compound at the interface to the base material. Consequently, the size of microscopic defects in the intermetallic compound has a dominant influence on the fracture stress. This behavior could nicely be explained with Finite Element simulations based on strain gradient elasticity.

• Periodical: Solid State Phenomena (Volume 258)
• Pages: 229-232
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.258.229
• Online since: December 2016
• Authors: Martin Lederer*, Golta Khatibi, Julien Magnien
• Keywords: Finite Element Method, Fracture Mechanics, Lead-Free Solder, Strain Gradient Theory

References

[1] Lederer M, Khatibi G and Weiss B (2012) Int. J. Solids Structures 49, 3453-3460.

[2] Lederer M, Khatibi G and Weiss B (2012), Chemical Monthly, 143: 1335-1339.

[3] Lederer, M., Magnien, J., Khatibi, G. Weiss, B., IOP conference series 602, (2015), 12020.

[4] Mindlin, R. D., Experimental Mechanics Vol. 3, (1963), pp.1-7.

[5] Lederer M, Khatibi G, WSEAS Transactions on Applied and Theoretical Mechanics, Volume 10, (2015), pp.213-219.

[6] Khatibi B, Lederer M, Byrne E, Betzwar-Kotas A, Weiss B, Ipser H, Journal of Electr. Mater., Vol. 42, (2013), pp.294-303.
