Process and Cost Improved Agitator Solutions for Bioleach Reactors

Abstract:

As mineralogy has become more complex in the long history of hydrometallurgical processing, the process routes and equipment used had to adapt to the changing conditions [1]. Hydrometallurgical bioleaching processes have been developed for different key metals such as gold, nickel and copper amongst others, to overcome the limitations of leaching sulphidic ores. The core of such a hydrometallurgical bioleaching plant is a cascade of stirred atmospheric tank reactors. Large volumes of air that are blown into these tanks must be dispersed by the agitator in order to provide the necessary oxygen mass transfer rates. At the same time the agitator system must be able to properly suspend all solids, homogenize the vessel contents and remove the exothermic reaction heat by inner tube bundles to achieve optimal reaction conditions. Besides the ‘economies of scale’ and advances in process results, cost optimization of such systems is fundamental. Therefore EKATO has developed the Combijet⁺ technology which has significantly reduced power requirements, compared to conventional agitators. Another advantage of the Combijet⁺ technology is that the gas is injected directly into the highest shear zones, at the impeller blades. As a result the oxygen mass transfer is improved and also substantial cost savings for compressor power are possible. The technical paper will present EKATO’s Combijet technologies which support the next step towards a new generation of biohydrometallurgical processing plants. It will also give examples of large scale commercial applications where this technology is successfully in operation.

• Periodical: Solid State Phenomena (Volume 262)
• Pages: 315-318
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.262.315
• Online since: August 2017
• Authors: Jochen Jung*, Wolfgang Keller
• Keywords: Combijet, Combijet⁺, Gas Sparger, Mass Transfer, Stirred Atmospheric Tank Reactors

References

[1] F. Abashi, A short history of hydrometallurgy, Hydrometallurgy. 79 (2005) 15-22.

[2] D.E. Rawlings, D.B. Johnson, A. Bakker, H.E. A Biomining, Springer Verlag, ISBN 103-3-540-34909-X.

[3] J. van Niekerk, J. W. Oliver, C. A. van Heuvel, Developing the next generation of BIOX® Design, ALTA Gold Proceedings (2012) 217 – 230.

[4] W. Keller, Considerations and Methodologies for the Design of Gassed Agitated CSTR's, ALTA Gold Proceedings (2010).

[5] BIOMIN Newsletter, May (2015).
