Technology of Mineral Raw Materials Granulation by Electric Arc for Manufacturing of Welding Fused Flux

Abstract:

The research and description of modern methods and procedure of welding flux manufacture are presented. The technology of welding fused flux production by influencing on the composition of mineral raw materials furnace burden (from 0,5 mic up to 0,20 mm) with electric arc (diameter graphite electrodes 6-18 mm, current from 200 up to 600 A) is proposed to be significantly reducing the labor input as well as dustiness during the operation and transport and improves mechanical properties (granules strength of 16-19 N/mm²) and surface condition of flux granules. The equipment for the granulation does not require large melting furnace and powerful transformers, fuel gas, coke or oil, i.e. welding flux is easy to manufacture.

• Periodical: Solid State Phenomena (Volume 265)
• Pages: 290-295
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.265.290
• Online since: September 2017
• Authors: Stanislav V. Naumov*, Michael N. Ignatov, M.A. Sheksheev
• Keywords: Comparative Analysis, Electric Arc, Fused Flux, Granulation, Melting, Minerals, Welding Material

References

[1] I.I. Liuborets, Welding fluxes, Technika, Kiev, (1984).

[2] V.V. Podgaevskii, V.G. Kuzmenko, Welding slag. Reference guide, Kiev, (1988).

[3] I.V. Gorynin et al., RU Patent 2387521 С2 (2012).

[4] I.M. Ignatov, S.V. Naumov, A.M. Ignatova, RU Patent 2494847 С1 (2013).

[5] I.V. Naidenov et al., RU Patent 2070499 (1996).

[6] V.I. Guzei et al., USSR Patent 1632713 А1 (1991).

[7] V.M. Chizhikova et al., RU Patent 2088669 (1997).

[8] A.V. Bychkov et al., RU Patent 2501751 (2013).

[9] N.F. Yakushevich et al., Using a ladle steelmaking slag in the production of ceramic welding flux, Vestnik SGIU, 3 (2015) 3-6.

[10] N.A. Kozyrev et al., Influence of carbon-fluorine welding fluxes additive on weld pollution with nonmetallic inclusions, Vestnik SGIU, 4 (2013) 20-24.

[11] N.A. Kozyrev, R.E. Kryukov, A.V. Roor, L.P. Bashchenko, U.I. Lipatova, New carbon-fluorine additives for welding fluxes, Steel in translation, 4 (2015) 251-253.

DOI: 10.3103/s0967091215040087

[12] D.A. Ademola, A.O. Festus, Mixture experiments and their applications in welding flux design, Journal of the Brazilian Society of Mechanical Sciences and Engineering, 30 (2008).

[13] S.C. Nwigbo, C.U. Atuanya, Formulation of a Metal Arc Welding Flux with a Potash Enriched Sodium Silicate Binder, Journal of Emerging Trends in Engineering and Applied Sciences, 3 (2012) 497-501.

[14] N.N. Potapov, A.I. Rymkevich, M.B. Roshchin, Special features of metallurgical processes in the electroslag welding of structural steels using fluxes with reduced basicity, Welding international, 6 (2012) 476-480.

DOI: 10.1080/09507116.2011.606165

[15] A.M. Ignatova, S.V. Naumov, M.N. Ignatov, S.A. Pushkin, S.B. Suslov, Assessment of the Suitability and Availability Basaltic and Gabbroic Complexes West of the Urals (Perm region) for Welding Materials, Vestnik PNIPU, 4 (2010) 104-116.

[16] A.O. Artemov, S.V. Naumov, A.M. Ignatova, M.N. Ignatov, Mineralogical and petrographic characterization of technogenic mineral resources of the Urals to their processing of stone casting, Georesursy, 6(48) (2012) 79–83.

[17] E.E. Kornienko, M.N. Ignatov, A.M. Ignatova, S.V. Naumov, A.Y. Chumachenko, Dependence of thermal expansion coefficients of metal and welding slag temperature in the range 100.. 1000 ºC, Obrabotka metallov, 3(56) (2012) 116–119.

[18] A.O. Artemov, S.V. Naumov, A.M. Ignatova, Informative Methods and Algorithms for Evaluating and Selecting Petrurgical Raw Materials, Scientific and technical Volga region bulletin, 4 (2012) 111-115.

[19] S.V. Naumov, Modern Methods of Grading Test of Powdered Components of Welding Materials, Vestnik PNIPU, 1 (2012) 76-84.

[20] S.V. Naumov, A.M. Ignatova, M.N. Ignatov, A.E. Kanina, On Fractional Composition of Welding Fluxes, Scientific and technical Volga region bulletin, 2 (2013) 166-169.
