Influence of Structure-Phase State on Surface Morphology of FeSi2 Nanofilms During RBE-MBE Growth on Si (001) 2×1

Nikolay I. Plusnin

doi:10.4028/www.scientific.net/SSP.312.62

Paper Titles

Investigation of the Mechanism of Electric Conductivity of Strontium Bismuthate Sr₆Bi₂O₁₁
p.32

Relationship between the Photoluminescence Spectra and IR Spectroscopy of Mesoporous Silicon Samples during Long-Term Storage: The Effect of Immersion in an Aqueous LiBr Solutions
p.38

Multilayer Heterostructures with Embedded CrSi₂ and β-FeSi₂ Nanocrystals on Si(111) Substrate: From the Formation to Photoelectric Properties
p.45

Relationship between the Photoluminescence Spectra and IR Spectroscopy of Mesoporous Silicon Samples during Long-Term Storage: The Effect of Immersion in an Aqueous Fe(NO₃)₃ Solutions
p.54

Influence of Structure-Phase State on Surface Morphology of FeSi₂ Nanofilms During RBE-MBE Growth on Si (001) 2×1
p.62

Theoretical and Experimental Studies of Structural Defects in CeO₂ Nanoparticles
p.68

Photocatalytic Reduction of CO₂ over Metal/BaTiO₃ Catalysts
p.74

Effect of Process Temperature on the Growth Kinetic and Structure of Ge Nanowires Formed by Galvanostatic Electrodeposition Using in Nanoparticles
p.80

Electrical Conductivity Study of the Adsorbate-Induced Si(111) Surface Reconstructions after C₆₀ Adsorption
p.86

HomeSolid State PhenomenaSolid State Phenomena Vol. 312Influence of Structure-Phase State on Surface...

Influence of Structure-Phase State on Surface Morphology of FeSi₂ Nanofilms During RBE-MBE Growth on Si (001) 2×1

Abstract:

The structure, phase composition, and morphology of FeSi and FeSi₂ nanofilms grown by three alternations of Fe (with a wedge-shaped thickness in the range 0 ‒ 2 ml) and Si (with a thickness 1 ML) depositions on a Si (001) 2×1 substrate heated to 400 °C were studied. According to Auger electron spectroscopy and electron energy loss, FeSi and FeSi₂ films were formed before and after the third deposition of Si, respectively. With this, a FeSi₂ film had ~1.5 ML of Si, which segregated on its surface. Both films consisted of a wetting coating (WL) and bulk phase forming at 2‒3 ML and after 3 ML of Fe, respectively. According to data of low electron energy diffraction, these films had a nanocrystalline structure. Moreover, according atomic force microscopy, deep square pores were formed in FeSi₂ films. They had a depth of 18‒10 nm, which was decreased and then increased before and, respectively, after Fe thickness ~ 3 ML.
