Technology and Equipment for Rolling of Bimetallic Bars with Multilateral Reduction

Abstract:

The article describes the technology and equipment used at the enterprises of the Russian Federation in 70-90 years in the XX century for the production of bimetallic rods, the basis of the new technology is described, and the designs of mills with multi-roller calibers are presented. New mill designs, patented in the U.S., Japan, Europe and other countries, have a fairly simple design, with the use of multi-roller mills it is possible to use drives from conventional two-roller mills, the presence of radial and axial adjustment of the rolls extends the technological capabilities of the mill, the calibers of different sizes can be obtained on a single set of rolls. On such mills it is possible to obtain sections from low plastic, difficult to deform materials, as well as bimetallic compositions. These products are in high demand in aviation, space, engineering and many other industries, which are strategic directions of the state development.

• Periodical: Solid State Phenomena (Volume 316)
• Pages: 418-425
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.316.418
• Online since: April 2021
• Authors: Marina N. Samodurova*, Leonid A. Barkov, Yuliya S. Latfulina
• Keywords: Bimetal Bar, Drive Rollers, Four-Roller Calibers, Idle Rollers, Rolling, Three-Roller Calibers, Two-Roller Calibers

References

[1] B.G. Grinberg, Yu.V. Knyshev. Multilayer metals in technology. Znanie, Moscow, 1969. (in Russian).

[2] E.A. Ulyanin. Corrosion Resistant Steels and Alloys: A Handbook. Metallurgiya, Moscow, 1991. (in Russian).

[3] A.Sh. Gindin et al. Production of double-layer corrosion-resistant sheets at the Chelyabinsk Metallurgical Plant. In: Resource conservation in the production of sheet metal: Abstracts of the All-Union Seminar, Moscow, (1990).

[4] Nomenclature of products of Mechel JSC Mechel JSC, Chelyabinsk, Russia, 1995. (in Russian).

[5] L.A. Barkov, V.P. Vostrikov, V.A. Shiypenkov. Production of electrotechnical cold—rolled sheets with corrosion-resistant coatings. Surface and Coatings 43/44 (1990) 554-566. (in Russian).

DOI: 10.1016/0257-8972(90)90106-m

[6] B.K. King, M.S. Gildengorn Basics of technology for the production of multilayer metals. Metallurgy, Moscow, 1970. (in Russian).

[7] M.I. Boyarshinov, M.I. Polyakov. The adhesion force of the clad layer and core during rolling. In: Metal forming: collection of scientific papers. Metallurgizdat: Sverdlovsk, 1962. (in Russian).

[8] L.A. Barkov. Patent USSR 1374597. (1987) (in Russian).

[9] L.A. Barkov, S.A. Mymrin et al. Patent USSR 778831. (1980) (in Russian).

[10] L.A. Barkov, S.A. Mymrin et al. Patent USSR 778837. (1980) (in Russian).

[11] L.A. Barkov, S.A. Mymrin et al. Patent USSR 828498. (1983) (in Russian).

[12] KOCKS: Continuous Rod Mills, USA, Pittsburgh, (2018).

[13] W.J. Ammerling, R.X. Holdom. Rolling of ultra precision bars with the Kocks three roll precision sizing block. In: Pres. 5th International Rolling Conference, London, 11—13 September (1990).

[14] P.M. Sychev, V.N. Vydrin, L.A. Barkov. Patent USSR 493260. (1973) (in Russian).

[15] V.N. Vydrin, L.A. Barkov et al. Patent USSR 753503. (1977) (in Russian).

[16] V.N. Vydrin, V.V. Pastukhov, L.A. Barkov, V.S. Sysoev. Patent USSR 753503. (1976) (in Russian).

[17] V.N. Vydrin, L.A. Barkov et al, Patent USSR 876217. (1978) (in Russian).

[18] A. Augusti, G. Fei. AF – rolling system: a new method of crimping workpieces. Steel Times International, January (1999) 24-26.

[19] X. Imamura, K. Omori, R. Takeda et al. Four-roll free-size rolling mill at the Kawasaki Steel plant, Japan. Steel Times International, September (1998) 27-28.

[20] S.A. Mymrin. Rolling of rods from tungsten and molybdenum powder blanks with four-side compression. Dissertation, Chelyabinsk Polytechnic Institute, Russia, 1985. (in Russian).

[21] L.A. Barkov. Fundamentals of the theory, the development and implementation of new processes for the rolling of high-quality sections from hardly deformable metals and alloys. Dissertation, Ural Polytechnic Institute, Russia, 1983. (in Russian).
