Thermal State Simulation of Welded Steel Plates under Laser Welding Conditions

Abstract:

The article describes a method for determination of the welded parts temperature pattern under laser welding conditions. An algorithm is engineered to solve the non-stationary heat conduction problem by finite element method. The boundary conditions are determined by the molten pool parameters and depend on the welding regime characteristics. The dependencies for determining the molten pool geometric dimensions for laser welding conditions are proposed. Calculations of the temperature pattern change during the steel plates joint by laser welding are carried out. It is shown that the proposed model adequately describes the heat transfer process in the welding region.

• Periodical: Solid State Phenomena (Volume 316)
• Pages: 396-401
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.316.396
• Online since: April 2021
• Authors: Aleksandr Ivanchenko*, I.P. Tochilin, Aleksey V. Zhdanov
• Keywords: Finite Element Method, Laser Welding, Molten Pool, Non-Stationary Heat Conduction Problem, Temperature Pattern

References

[1] Rassolov, T. V., Aborkin, A. V. and Ivanchenko, A. B., Effect of residual welding stresses on the fatigue durability of boiler plants, Modern problems of science and education, 2011, № 6.

[2] Ivanchenko, A. B, Belyaev L. V., Zhdanov A. V., Morozov V. V. Temperature state and residual deformations in a welding conditions study, Future Communication Technology and Engineering - Proceedings of the 2014 International Conference on Future Communication Technology and Engineering, FCTE 2014, pp.183-185.

DOI: 10.1201/b18331-43

[3] Grigoryants, A. G., Technological processes of laser processing: manual for universities, Grigoryants A. G., Shiganov I. N. and Misyurov A. I., Ed. Grigoryants A. G., 2nd Ed., Moscow, Bauman Moscow State Technical University, 2008, 663 p.

DOI: 10.17580/tsm.2018.10.11

[4] Rykalin, N. N., Calculation of heat processes in welding, Moscow, Mashgiz, 1951. 296 p.

[5] Petrov, G. L. and Tumarev, A. S., Theory of welding processes (with the basics of physical chemistry), Textbook for universities, Moscow, Vysshaya shkola, 1977, 393 p.

[6] Shapeev, V. P., Isaev, V. I. and Cherepanov, A. N., Numerical simulation of laser welding of metallic plates, Physical mesomechanics, 2011, Vol. 14, № 2, pp.107-114.

[7] Shapeev, V. P., Isaev, V. I. and Cherepanov, A. N., Numerical simulation of laser welding of thin metallic plates taking into account convection in the welding pool, Thermophysics and Aeromechanics, 2010, № 3, pp.451-466.

DOI: 10.1134/s0869864310030133

[8] Ershov, G. S. and Chernyakov, V. A., Structure and Properties of Liquid and Solid Metals), Moscow, Metallurgiya, 1978, 248 p.

[9] Zinoviev, V. E. Thermo physical properties of metals at high temperatures, Moscow, Metallurgiya, 1989, 384 p.

[10] Usov S. V., Tochilin, I.P., Zhdanov A.V., Voznesenskaya A.A. Development of automation systems and information technologies that reduce the time of the creation and development of the new medical devices (monograph), Moscow, 2019, 130 p.

[11] Grigoryants A. G., Misyurov A. I., Shiganov I. N., Perestoronin, A. V., Asyutin R. D. and Usov S. V. Shaping of the melt bath during laser alloying of the surface of binding steel // Welding production/2019, #7, pp.17-22.

DOI: 10.1080/09507116.2021.1901453
