Development of Arc Welding Technology with Support of Stability of Electrode Melting Process

Abstract:

Mechanized arc welding is divided into two main varieties: with self-regulation of the electrode melting process and with automatic process control. The common thing between self-regulating mechanized arc welding and manual arc welding is that in the welding equipment there are no means for automatic control with feedback from the arc. The difference between them is that stabilization of the electrode melting process in mechanized welding is carried out by the source itself, which has a particular volt-ampere characteristic (CVC), by a corresponding spontaneous reaction to a change in the situation in the arc. This method is significantly inferior to the method with automatic process control in precisely maintaining the specified parameters and has a limitation on the minimum current density on the electrode. The method of pulse self-regulation of the electrode melting process proposed in the E.O.Paton EWI removes this problem. However, it requires the use of power sources with a complicated, multi-link CVC curve. Further improvement is revealed through the use of digital controlled, programmable power supplies that have an automatically generated CVC. The combination of automatic source control and self-regulation by the spontaneous reaction to the situation in the arc creates a new hybrid way to stabilize the process of arc welding with a consumable electrode and other related arc processes (surfacing, soldering, re-melting).

• Periodical: Solid State Phenomena (Volume 316)
• Pages: 582-588
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.316.582
• Online since: April 2021
• Authors: V.S. Sidoruk, S.Yu. Maksimov*, D.N. Krazhanovskyi
• Keywords: Automatic, Control, Digitalization, Hybrid, Manual, Self-Regulation, Stability, Welding

References

[1] B.E. Paton, Problems of welding of the turn of the century, Avtomaticheskaya Svarka, 1 (1999) 4-14.

[2] Technology of electric welding of metals and alloys by fusion, B. Paton (ed), Engineering, Moscow, (1974).

[3] B.E. Paton, V.S. Sidoruk and S.Yu. Maksimov, Pulsed self regulation melting of electrode process, LAP LAMBERT Academic Publishing, Saarbrucken, Germany, (2016).

[4] D. M.Pogrebisky, Welding of Metals: Classification, Brief History, Development, INSTY PRINTS, Jerusalem, (2016).

[5] D. Bruce, Assessing the Benefits of Surface Tension Transfer â Welding to Industry, Journal of Industrial Technology, 19 (2003) 2-7.

[6] Yu. Saraev, Development of adaptive pulsed technological processes of welding and surfacing, Dissertation, TSNIIMASH, Moscow, (1995).

[7] H. Hacke, K. Himmelbauer, The CMT-Process-A Revolution in Welding Technology, IIW Doc. №ХII – 1875 – 05, (2005).

[8] B.E. Paton, Self – regulation of arc welding using consumable electrode, Avtomaticheskaya Svarka, 1 (1952) 38-45.

[9] V.S. Sidoruk, D.A. Dudko and A.F. Tsvigun, Automodulation of current in Submerget Arc Welding, Avtomaticheskaya Svarka, 5 (1987) 25-28.

[10] B. Paton, Memories. State publishing house of fiction, Kyiv, (1956).

[11] V.A. Lenivkin, D.V. Kiselev, Peculiarities of self-regulation of electrode melting, Vestnik of the DSTU, 44 (2010) 95–101.

[12] P.V. Gumkov, B.I. Nosovsky, V.N. Matvienko et al., SU Patent 1547986. (1990).

[13] B.E. Paton, S.Yu. Maksimov, V.S. Sidoruk and Yu.N. Saraev, Regarding the issue of arc self-regulation in consumable electrode welding, Svarochnoye Proizvodstvo, 12 (2014) 3–11.

DOI: 10.1080/09507116.2015.1012381

[14] B. Paton, I. Krivtsun, V. Sidoruk, S. Maksimov and G. Kolesnik, UA Patent 104214. (2014).

[15] B.E. Paton, V.S. Sidoruk, RU Patent 2021086. (1994).

[16] O.U. Zhimihng, W. Yong, U. Masao, T. Manabu, New Concept for the Characteristic of an Arc Welding Power Source (Report II), Trans. JWRI, 28 (1) (1999) 26-38.

[17] B. Paton, V. Sidoruk, S. Maksimov and D. Krazhanovsky, UA Patent 106293. (2014).

[18] B. Paton, S. Maksimov, V. Sidoruk, UA Patent 113883. (2017).

[19] B. Paton, V. Sidoruk, S. Maksimov et al., UA Patent 110397. (2015).

[20] S. Maksimov, V. Sidoruk, A. Korotynsky et al., UA Patent 110556. (2016).

[21] A. Pirumov, I. Skachkov, S. Suprun and S. Maksimov, Specialized information-measuring system for monitoring the process of arc welding, Avtomaticheskaya Svarka, 8 (2007) 41-43.
