Vibration Control and Design of Vehicle Engine Mount Activated by Magnetorheological Fluid

Abstract:

Magneto-rheological (MR) fluid mount demonstrates excellent performance of vibration isolation in a wide frequency range and potential application in engineering. In this paper, a new mixed mode MR mount is proposed and an analytical model is established and used to predict the performance of MR mount. Meantime, a six degrees of freedom dynamic model of an in-line four-cylinder engine which has three points mounting system is derived by considering the dynamic behaviors of MR mount and its state space form is established. LQR and fuzzy-logic controllers are designed and synthesized to actively control the imposed vibration. The simulation results show that the proposed LQR or fuzzy-logic controllers can isolate the vibration of vehicle engine in a wide frequency range. The amplitudes can be suppressed well by employing this mount system. Its effectiveness will be verified via experiment in the second part of this work.

• Periodical: Advanced Engineering Forum (Volumes 2-3)
• Pages: 1077-1081
• DOI: https://doi.org/10.4028/www.scientific.net/AEF.2-3.1077
• Online since: December 2011
• Authors: Zhao Xue Deng, Ling Zheng
• Keywords: Fuzzy Logic Controller, LQR, Magnetorheological Mount, Vehicle Engine

References

[1] Kim G, Singh R. Nolinear analysis of automotive hydraulic engine mount. Journal of Dynamic System, Measurement and Control 1922; 115(2): 482-7.

[2] Ushijima TK, Takano K, Kojima H. High performance hydraulic mount for improving vehicle noise and vibration. SAE Technical Paper Series 8800773.

DOI: 10.4271/880073

[3] Elahinia M, Nguyan T, Ciocanel C, Parameter optimization in designing an MR mount, Proceeding of 15th International Congress on Sound and Vibration, 6-10 July, 2008, Daejeon, Korea. SS0561: 237.

[4] Young Kong Aha, Bo-Suk Yang, Mehdi Ahmadian, Shin Morishita, A Small-sized Variable-damping Mount using Magnetorheological Fluid, International Journal of Vehicle Design, Vol. 16 February (2005).

DOI: 10.1177/1045389x05048041

[5] Sung-Ryong Hong, Seung-Bok Choi, Vibration Control of a Structural System Using Magneto-Rheological Fluid Mount, Journal International Material System And Structures, (2005).

DOI: 10.1177/1045389x05053917

[6] Seung-Bok Choi, Sung-ryong Hong, Kum-Gil Sung, Jung-Woo Sohn, Optimal control of structural vibrations using a mixed-mode magnetorheological fluid mount. International Journal of Mechanical Sciences, 2008, 50: 559-568.

DOI: 10.1016/j.ijmecsci.2007.08.001
