An Experiential Optimization Design Method for Orthogonal Rib-Stiffened Thin Walled Cylindrical Shells under Axial Loading

Abstract:

Parametric structural FEA (Finite Element Analysis) models of the orthogonal rib-stiffened thin walled cylindrical shells are established using APDL (ANSYS Parametric Design Language). An experiential optimization design method is then developed based on conclusions of series numerical analysis investigating the effects of parameters’ modification upon buckling loads and modes of the structure. The effects of single design parameter modification under both variational and fixed volume (mass) constraints upon the buckling loads and modes indicate that, only one design scheme is able to obtain maximum buckling load when deployment of the strengthening ribs and volume (mass) parameter were settled previously, and minimum mass would be obtained while this maximum buckling load equals to the required design load. Optimization calculations for aluminum alloy material and layered C/E (Carbon/Epoxy) composite material shells with three layering styles are implemented and discussed, and some useful conclusions are obtained. Method and approach developed in this paper provide certain reference value for the optimal design of such structures.

• Periodical: Applied Mechanics and Materials (Volumes 110-116)
• Pages: 1773-1783
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.110-116.1773
• Online since: October 2011
• Authors: Jia Mao, Yu Feng Chen, Wei Hua Zhang
• Keywords: Experiential Method, Finite Element Method (FEM), Optimization Design, Orthogonal Rib-Stiffened Thin Walled Cylindrical Shell, Parametric FEA Model

References

[1] Wang XinQing. Structure design[M]. Beijing: Space Navigation Press, 1994: 6-7; 52-56 (In Chinese).

[2] Huang QiZhen. Missile structurematerialstrength[M]. Beijing: Space Navigation Press, 1996: 9-11; 179-190 (In Chinese).

[3] P. M. Weaver. Design of laminated composite cylindrical shells under axial compression [J]. Composites, Part B: engineering, 2000(31): 669-679.

DOI: 10.1016/s1359-8368(00)00029-9

[4] J.W. Hutchinson , M.Y. He. Buckling of cylindrical sandwich shells with metal foam cores [J]. International Journal of Solids and Structures, 2000(37): 6777-6794.

DOI: 10.1016/s0020-7683(99)00314-5

[5] Navin Jaunky and Norman F. Knight, Jr. Optimal design of general stiffened composite circular cylinders for global buckling with strength constraints [C]. AIAA-97-1402, (1997).

DOI: 10.2514/6.1997-1402

[6] Y. Goldfeld. Buckling and initial post-buckling of generally stiffened conical shells [C]. AIAA-2006-2275, (2006).

DOI: 10.2514/6.2006-2275

[7] Jan de Vries. Analysis of localized buckling of cylindrical shell using a hierarchical approach [C]. AIAA-2006-2274, (2006).

[8] Jan de Vries. Localized buckling of imperfect cylindrical shell, a modified FEM approach [C]. AIAA-2007-2226, (2007).

DOI: 10.2514/6.2007-2226

[9] David Bushnell. Optimization of an axially compressed ring and stringer stiffened cylindrical shell with a general buckling modal imperfection [C]. AIAA-2007-2216, (2007).

DOI: 10.2514/6.2007-2216

[10] Cui DeGang. Structure stability design manual [M]. Beijing: Aeronautics Industrial Press, 2006: 178-179; 50-52 (In Chinese).
