Study of Pre-Tightening Force on Piezoelectric Multi-Dimensional Force Sensor’s Measurement Performance

Abstract:

In this paper, the pre-tightening force on piezoelectric multi-dimensional force sensor is researched. Structure of multi-dimensional force sensor and piezoelectric quartz crystals are introduced and analyzed. The relationship between pre-tightening force and measuring range of force sensor is researched. Structural model of multi-dimensional force sensor is built and analyzed by FEM. Horizontal linearity in horizontal direction with different preloads is obtained. In order to verify FEM analysis, a reduced prototype of piezoelectric multi-dimensional force sensor is fabricated. Verification test is designed and made. The research will provide certain reference value for development of piezoelectric multi-dimensional force sensor.

• Periodical: Applied Mechanics and Materials (Volumes 117-119)
• Pages: 656-659
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.117-119.656
• Online since: October 2011
• Authors: Ying Jun Li, Gui Cong Wang, Chang Chun Li, Chang Sheng Ai
• Keywords: FEM Analysis, Force Sensor, Piezoelectric, Pre-Tightening Force

References

[1] M. H. Huang, Y. J. Gong, MEASUREMENT & CONTROL TECHNOLOGY (1989), volume 11, pp.10-13.

[2] J. T. Yao, Y. L. Hou, J. Y. Niu, Chinese Journal of Scientific Instrument (2009), volume 30, pp.1233-1237.

[3] Y.J. Li, J. Zhang, Z. Y. Jia , M. Qian, Mechanical Systems and Signal Processing, Elsevier (2009), 23 (5), pp.1644-1651.

[4] Y.J. Li, J. Zhang, Z. Y. Jia , M. Qian, H. G. Li, Mechanical Systems and Signal Processing, Elsevier (2009), 23(8): 2687-2698.
