The design and development of embedded configuration software is becoming one of the most important issues, the aim is to achieve mission-specific tasks and integrate supervisory management and control function in a collaborative way. In order to deal with the design and development of configure software for heavy-duty vehicle, object-oriented programming method is employed. At the same time, graphic-based display is realized using class object conception, and double buffering mechanism is proposed to improve graph display performance, furthermore, XML based serialization is employed to store the graph repository. The development environment and entire design process are based on the c sharp platform to take advantages of compatibility and scalability as well as meet further improvement. A snapshot of the graphic interface realization is shown to validate the design method.
