Study on Dual-Loop Controller of Helicopter Based on the Robust H-Infinite Loop Shaping Method

Abstract:

Helicopter is a typical MIMO system including the properties of non-stability, strong coupling, uncertainty. Firstly, a robust internal loop ACAH controller is designed and analyzed to ensure decoupling and robustness on each channel by the robust H-infinite loop shaping. Secondly, the external loop is designed using the classical PID method on the base of decoupling internal loop. Both loops contain the part of anti-windup. The simulation results of the prototype model demonstrate that in both time and frequency domain, the performance of the controller meets the design requirement with a comparative simple structure. The results can also prove that it has some effect against to the model perturbation and achieve LEVEL1 of ADS-33E-PRF.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 1182-1185
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.1182
• Online since: October 2011
• Authors: Zhe Yan Lang, Ai Guo Wu
• Keywords: Decouple, Dual-Loop, Helicopter, Model Perturbation, PID, Robust H-Infinite Loop Shaping

References

[1] Hu B G, Mann G. K I, Gosine R G: A systematic study of fuzzy PID controllers-function-based evaluation approach. IEEE Transactions on Fuzzy systems, Vol. 9(5) (2001), p.699~712.

DOI: 10.1109/91.963756

[2] Kim B S, Calise A J: Nonlinear flight control using neural networks. AIAA Journal of Guidance, Control and Dynamics, Vol. 20(1) (1997), p.26~33.

DOI: 10.2514/2.4029

[3] Huang Yimin, Guo Suofeng: Inner/Outer Loop Design Concept and Its Application to Flight Control System. Journal of Nanjin University of Aeronautics & Astronautics, Vol. 31(3) (1999), pp.287-292. (in Chinese).

[4] Tang Yongzhe: Helicopter Control System Design. National Defence Industry Press, 2000. (in Chinese).

[5] Yang Yidong: Flight Control for Helicopter. National Defence Industry Press. 2007. (in Chinese).
