Isolation Performance Evaluation of Compressor Vibration Isolating Systems Based on LMS Test. Lab Signature

Abstract:

In order to reduce vibration and noise of the compressor used in small and medium-sized refrigeration unit, this paper designs different vibration isolating systems and carries out experiment of isolation performance evaluation based on LMS Test. Lab Signature software. The comparison results of four different vibration isolating systems show that the peak values of vibration velocity response in each system mainly appear at 25Hz, 50Hz, 75Hz and 100Hz, and the maximum velocity does not exceed 22mm/s which is less than the maximum allowed by the national standard^[1]. And the Vibration Level Difference (VLD) is taken as evaluation criteria for isolating vibration, that of single-layer vibration isolating system is within 10-20dB, and that of double-layer vibration isolating system is within 20-35dB. Furthermore with the increase of middle-mass, the VLD has a clear upward trend.

You might also be interested in these eBooks

Mechanical and Electronics Engineering III

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 130-134)

Pages:

1220-1225

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.130-134.1220

Citation:

Cite this paper

Online since:

October 2011

Authors:

Li Zhang, Hao Chen, Yan Jue Gong, Hong Wu, Shuo Zhang

Keywords:

Compressor, Isolation Performance Evaluation, Lab Signature, LMS Test, Vibration Isolating System, Vibration Level Difference

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] GB/P 50463-2008. Code for design of vibration isolation [S]. Beijing: China Planning Press, 2009: 11-12.

Google Scholar

[2] Bu Xiaoyuan, Zhang Li, Chen Hao: LMS Experimental modal analysis of compressor vibration isolation component for food refrigerating unit [J]. Journal of Beijing technology and business university (natural science edition), 2010, 28(6): 36-41.

Google Scholar

[3] Chen Hao, Zhang Li, Wu Hong, Zhang Shuo: Dynamics analysis of vibration isolation system for compressor of food refrigerating unit based on Ansys. Journal of Beijing technology and business university (natural science edition), 2011, 29(4): 42-48.

Google Scholar

[4] Zhu Shijian et al: Vibration theory and isolation technology [M]. Beijing: National Defense Industry Press, 2008: 231-245.

Google Scholar

[5] Lin Guoji: Application of mechanical vibration learning [M]. Taiwan: Xiao Park Press, 1994: 86-94.

Google Scholar
