Solution of Constraint Force of Frame with Shape of T by Principle of Conversion Method

Abstract:

Owing to lack of geometric method for calculating frames with the shape of T, the conversion method is used to resolve the frames in which no joint has lateral displacement. It puts forward the analysis steps of the solution of the frame. The concrete process of calculation belongs to primary computation of algebraic equation. It gets analytic solution. The calculation sequence of an example of a frame is advanced.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 3107-3110
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.3107
• Online since: October 2011
• Authors: Xiao Jin Yu
• Keywords: Analogy, Cantilever Beam, Constraint Force, Conversion Method, Displacement, Frames
