Experimental Research of Strain and Temperature Based on EFPI Sensor

Abstract:

An extrinsic Fabry-Perot (F-P) interferometric (EFPI) sensor by using simple etching and fusing method is proposed and demonstrated. The cavity is formed by wet chemical etching of multi-mode fiber (MMF) end face in hydrofluoric acid solutions, and then it is fused to the end of a single-mode fiber (SMF) to form an extrinsic F-P structure. The strain and temperature of EFPI sensor are studied experimentally. The experimental results show that the interference wavelength becomes 2.648nm longer while the strain increases from 0N to 637N, and the strain sensitivity is about 0.004nm/N, and linearity is 0.999. The interference wavelength becomes 0.032nm shorter while the temperature increases from 20°C to 100°C. This kind of sensor has the many advantages of easy fabrication, good reliability, high-repetition, small size, low cost and mass-production, which offers great prospect for sensing applications.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 4185-4188
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.4185
• Online since: October 2011
• Authors: Xiu Feng Yang, Chun Yu Zhang, Zheng Rong Tong
• Keywords: Etch, Fabry-Perot Cavity, Strain, Temperature

References

[1] Y. J. Rao, M. Deng, and D. W. Duan Micro et al. Fabry-Perot interferometers in silica fibers machined by femtosecond laser. Optics Express, Vol. 15(2007), pp.14123-14128.

DOI: 10.1364/oe.15.014123

[2] X. Wan and H.F. Taylor. Intrinsic fiber Fabry-Peort temperature sensor with fiber Bragg grating mirrors . Optics. Letters, Vol. 27(2002), pp.1388-1390.

DOI: 10.1364/ol.27.001388

[3] Murphy K.A., Gunther M.F., Vengsarkar A.M., et al. Fabry-Perot fiber optic sensors in full-scale fatigue testing on F-15 aircraft. Proceedings of SPIE, Fiber Optic Smart structures and Skin IV, Vol. 1588(1991), pp.134-142.

DOI: 10.1117/12.50172

[4] H.Y. Choi M.J. Kim, and B.H. Lee. All-fiber Mach-Zehnder type interferometers formed in photonic crystal fiber. Optics Express, Vol. 15(2007), pp.5711-5720.

DOI: 10.1364/oe.15.005711

[5] Jonathan Masson, Raphael St-Gelais, and Student Member et al. Tunable Fiber Laser Using a MEMS-Based In Plane Fabry-Perot Filter. IEEE Journal of Quantum Electronics, Vol. 46(2010), pp.1313-1319.

DOI: 10.1109/jqe.2010.2050299

[6] O. Frazao, S. H. Aref, and J. M. Baptista, et al. Fabry-Perot cavity based on asuspended-core fiber for strain and temperature measurement. IEEE Photonics Technology Letters, Vol. 21 (2009), pp.1229-1231.

DOI: 10.1109/lpt.2009.2024645

[7] Zheng Yuhuang, Yi Zhengzhu, Xiao Peichen, et al. Intrinsic fabry–perot fiber sensor for temperature and strain measurements. IEEE Photonics Technology Letters, Vol. 17(2005), pp.2403-2405.

DOI: 10.1109/lpt.2005.857236
