Performance Predication and Axial Force Study on Deep-Well Centrifugal Pump

Abstract:

Axial force is one of the main factors which affect the pump safety and reliability during the operation of pumps, especially in multi-stage centrifugal pumps. 150QJ20 type deep-well centrifugal pump (DCP) is selected as an example to research the pump performance and axial force with the numerical simulation and experiment method. The numerical simulation results were compared with experimental measurements, and such result was analyzed. The results show that the change trend of the pump performance and axial force acquired by numerical and experiment is similar. At rated operating point, the error of axial force between the numerical simulation and experimental measurements is less than 3%. This confirmed the feasibility of predict the pump performance by numerical simulation method.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 711-714
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.711
• Online since: October 2011
• Authors: Ling Zhou, Wei Dong Shi, Wei Gang Lu, Hui Li
• Keywords: Axial Force, Deep-Well Centrifugal Pump, Numerical Simulation, Performance

References

[1] Shi WD, Lu WG, Wang HL, Li QF. Research on the theory and design methods of the new type submersible pump for deep well [C]/ASME Conference Proceedings, FEDSM2009, 2009, 1: 91-97.

[2] Shukla S, Kshirsagar J. Numerical experiments on a centrifugal pump [C]. ASME Conference Proceedings, FEDSM2002, 2002, 2: 709~720.

[3] Rikke K, Christian P B, Nieholas. Flow in a centrifugal pump impeller at design and off-design conditions-part Ⅱ: large eddy simulations [J]. Journal of Fluids Engineering, 2003, 125(1) 73~83.

DOI: 10.1115/1.1524586

[4] Deigosha OC, Patella RE, Reboud JL, etc, al. Experimental and numerical studies in a centrifugal pump with two-dimensional curved blades in cavitating condition [J]. Journal of Fluids Engineering, 2003, 125(6): 970~978.

DOI: 10.1115/1.1596238
