Numerical Study on Hydrodynamic Behavior of Deepwater Spar Platform with Different Mooring Configurations

Abstract:

The motion performance of Spar platform and dynamic characteristics for the mooring lines under different mooring configurations have been studied both in static analysis and coupled dynamic analysis. First, 3D hydrodynamic finite element model is built and the effects of the mooring system are taken into account by giving the specified pre-tension, angle and stiffness of the mooring lines on the fairleads. And hydrodynamic analysis of Spar platform is performed by the way of utilizing potential flow theory in frequency domain in order to calculate the hydrodynamic coefficients. Then, static analysis is applied to obtain restoring stiffness curves for the mooring system, structure displacements and mooring line tensions etc.. At last, coupled time domain analysis of the motion response of Spar is conducted for the coupled system and the dynamic tensions of mooring lines are calculated. The research results can be served as a reference for the selection and the performance study for mooring systems during preliminary design.

• Periodical: Applied Mechanics and Materials (Volume 137)
• Pages: 50-58
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.137.50
• Online since: October 2011
• Authors: Jin Wei Sun, Xiu Tao Fan, Xiao Zheng Wan, Shi Xuan Liu
• Keywords: Coupled Analysis, Deepwater, Mooring Configuration, Spar Platform

References

[1] Tong Bo, Yang Jianmin, LI Xin, Coupled dynamic analysis of catenary mooring system for the deepwater semi-submerged platform, J. China Offshore Platform. 23, (2008) 2-7.

[2] Chen Xujun, Tang Xuefeng et al, Theoretical analysis of mooring chain disposition for a float-body,J. Journal of Hehai University (Natural Sciences). 29, (2001) 84-87.

[3] T.M. Smith, M.C. Chen et al, Systematic data for the preliminary design of mooring systems.Proceedings of the fourth International Offshore Mechanics and Arctic Engineering Symposium. 1, ( 1985) 403-407.

[4] XiaoYue, Wang Yanying, The calculation and analysis for the moored system, J. China Offshore Platform. 20, (2005) 37-42.

[5] Per.I.Johansson, A finite element model for dynamic analysis of mooring cables, MIT, 1976.

[6] Mark A. Grosenbaug, A simple model for heave-induced dynamic tension in catenary moorings, J. Applied Ocean Research. 23, (2001) 159-174.

DOI: 10.1016/s0141-1187(01)00013-x

[7] Deep water coupled floater motion analysis, DNV, 2005.
