Experimental Modal Analysis of Fan Vibration Frequency

Abstract:

Fan is used for pneumatic conveying grain in the 4ZTL-1800 combine harvester threshing prior to cutting. In order to decrease power consume of it, the experimental modal analysis of fan was done by using hammer-hitting pulse-inspirit method. The natural frequencies of fan vibration is obtained, which is contrasted with inspirit frequency of fan, then resonance vibration of fan is found and its frequency is at 125Hz, which verifies the result of the experimental modal analysis.The results are beneficial to decrease power consume of fan.

• Periodical: Applied Mechanics and Materials (Volumes 138-139)
• Pages: 395-398
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.138-139.395
• Online since: November 2011
• Authors: Li Jun Wang, Zhi Yang Pan
• Keywords: Combine Harvester, Experimental Modal Analysis, Fan, Threshing Prior to Cutting, Vibration Frequency

References

[1] Enchen Jiang: A Stripping Unit and Pneumatic Conveying System for Grain Harvesting. Beijing: Higher education press., Chinese, (2002).

[2] Yijun Mao, Datong Qi and Qiuhong Liu: submitted to Journal of Xi'an Jiaotong Niversity (2005).

[3] Chuzhou Tang, Xiaoying Zhang and Zhonghe Ouyang: submitted to Transactions of the CSAE (2007).

[4] Iwasaki M, Sasao A and Sakai K: submitted to Journal of the Japanese Society of Agricultural Machinery (2005).

[5] Silva R P, Da Fontana G and Lopes A: submitted to Engenharia Agricola (2004).

[6] Sun shaoming, Ren luquan and Meitao: submitted to Journal of Vibration and Shock(2009).

[7] Dong Li and Jianming Gu: submitted to journal of the Technology of Fan (2004).

[8] Gang Ren, Zishan Yang and Zijiang Yang: submitted to journal of the Fluid Machinery (2010).
