Stability Analysis of Turning Process Based on a 2-DOFs Model with Overlap Factor

Abstract:

A new 2-DOFs dynamic turning model including the compliance of workpiece and cutting tool is developed. In past studies, most of them were based on SDOF models and either the workpiece or tool was simplified as rigid one. Meanwhile, traditional regenerative chatter models focus mainly on cross cutting which was particularly prone to chatter. It is evident that such models cannot descript cutting system comprehensively. In order to tackle this problem, we introduce the overlap factor making the new model also suitable for length-wise cutting. Stability was analyzed after performing the Laplace transformation, correlation between critical chip width and spindle speed was derived. Simulation suggests that the new model has a larger critical chip width which complies with practical situation.

• Periodical: Applied Mechanics and Materials (Volume 141)
• Pages: 508-512
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.141.508
• Online since: November 2011
• Authors: Lai Xi Zhang, Xing Song Wang, Shu Lin Liu
• Keywords: 2-DOFs Model, Chatter, Overlap Factor, Regenerative, Stability Analysis

References

[1] R.S. Hahn: Trans. A.S.M. E Vol. 76(1954), pp.593-597.

[2] J. Trustly, M. Polacek: International Research in Production Engineering, ASME. New York, (1963), pp.465-474.

[3] S.A. Tobias: Machine Tool Vibration (BLACKIE, London 1965).

[4] Choudhury, S. K., N. N. Goudimenko, et al: International Journal of Machine Tools and Manufacture Vol. 37 (1997) No. 6, pp.801-811.

DOI: 10.1016/s0890-6955(96)00031-4

[5] Clancy, B. E., Y. C. Shin: International Journal of Machine Tools and Manufacture Vol. 42 (2002)No. 9, pp.1035-1044.

[6] Budak, E., E. Ozlu: CIRP Annals - Manufacturing Technology Vol. 56 (2007) No. 1, pp.401-404.

[7] Bisu, C., J. -Y. K'nevez, et al: International Journal of Material Forming Vol. 2 (2009) No. 2, pp.93-105.

[8] Bisu, C., P. Darnis, et al: The International Journal of Advanced Manufacturing Technology Vol. 44 (2009) No. 1, pp.1-16.

[9] Litak G: Chaos, Solitons & Fractals Vol. 13 (2002), p.1531–5.

[10] G. Stépán: Trans. R. Soc. Lond. A Vol. 359 (2001), pp.739-757.

[11] X. S Wang, J. Hu, et al: Chaos, Solitons and Fractals Vol. 29 (2006), pp.1219-1228.
